Air source heat pump water heaterAir heat energy applies reverse Carnot principle by using electric energy to make refrigerant
Air source heat pump water heater
This is our new products which is started to come into the domastic market from Dec. 2008.
Cooperated with ZHEJIANG UNIVERSITY( famous), we engineer Jiadele air source heat pump which is a saving energy products. It uses the thermal energy from air to produce the hot water about 55-60 centigrade. It is used widely in schools hospitals hotels and so on.
JIADELE commercial air source heat pump water heater specification:
Specifications Model: |
JDL165/L |
JDL-330/T |
|
Heating |
KW |
16.5 |
33.0 |
Heating consumption power |
KW |
4.82 |
9.64 |
Heating operating current |
A |
8.36 |
16.72 |
Power |
380V/50HZ |
380V/50HZ |
|
Compressor type |
Full-closed scroll compressor |
Full-closed scroll compressor |
|
Compressor quantity |
1 |
1 |
|
Compressor oil heating power |
W |
70 |
70 |
type |
Brazed plate heat exchanger |
Brazed plate heat exchanger |
|
Evaporator water flow |
Cbm/h |
0.41 |
0.82 |
Evaporator water pressure drop |
kPa |
50 |
50 |
Out water temperature |
C |
55(MAX: 60C) |
55(MAX: 60C) |
Water pipe connection |
in |
3/4 |
1 |
Condensing fan type |
high-efficiency axial fan |
high-efficiency axial fan |
|
Condensing fan blowing type |
Side blowing |
Side blowing |
|
Frozen oil type |
Sontex200LT |
Sontex200LT |
|
Frozen oil quantity |
L |
1.95 |
1.82 |
Refrigerants type |
R22 |
R22 |
|
Refrigerants saving way |
Thermal Expansion Valve |
Thermal Expansion Valve |
|
Refrigerants quantity |
kg |
2.3 |
4.6 |
Measurement |
1000×540×1570 |
1350×600×1430 |
|
Noise |
≤dB (A) |
60 |
60 |
Weight |
kg |
180 |
280 |
working environment: Outside temperature is 20C; wet bulb temperature is15C; Inlet water temperature is 20C; outlet water temperature is 55C | |||
