High voltage testing equipmet impulse current generator
USD $20,000 - $500,000
/ Set
1 Set(Min.Order)
- 20 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A
You May Like
-
Standard lightning impulse current generator HV test system
-
Multi waveshape impulse current generator combination wave test system
-
Impulse Current Generator HV test system with explosion proof protection equipment
-
2mS square wave HV impulse generator high current test system
-
Standard lightning impulse current generator 8/20 LI waveshape test system
-
Impulse Current Test Systems Surge Generator
Quality Choice
Product Details
| Place of Origin | China | Brand Name | FSHV | |
| Model Number | FICG-D |
Product Description
Specifications
Generate 1/20us, 4/10us, 8/20us, 10/350us, 18/40us, 30/80us, 2000us and other impulse current waveforms as per IEC standardHigh voltage testing equipmet impulse current generator
Introduction
FICG series impulse current test systems can generate 1/20μs, 4/10μs, 8/20μs, 10/350μs, 18/40μs, 30/80μs, 2000μs and other standard impulse current waveforms as per IEC standard, the impulse current of 8/20μs LI up to 240kA, 10/350μs SI up to 200kA, and combination of multiple waveforms is available.
Application
Impulse current test systems are mainly used for withstand impulse current test of arresters and components, surge protector and varistors, discharge tubes, also for meteorological lightning, earthing resistance measurement and other research test.
Reference
| |
| |
| |
| |
Company Information
We are the leading and earliest manufacturer of high voltage, high current and high power test system in China, provide AC, DC, impulse testing and associated measuring equipment used to electrical application, such as testing project of power cables, power transformers, GIS switchgears, insulators, generators, arresters and etc. And test systems for laboratory, factory and field use are available.
Our factory was founded in 1970, and established R&D center institute of HV testing equipments in 1986, which cooperated with Shanghai Jiaotong University.
We are pleased to announce our quality management system has been approved to ISO 9001 : 2008, so far we have applied more than 58 invention patents.
We have well cooperated with many world famous electrical corporations, like ABB, ALSTOM, SIEMENS, TOSHIBA, HITACHI, HYUNDAI, AE POWERS and etc, also state grids, research institutes, universities and HV testing service providers, we have successfully offered them plenty of high voltage test systems, all well performed.
Our new factory is under construction, which will go into service in 2015, it will become the biggest manufacturer of high voltage testing equipment all over the world.
