Home > Electrical & Electronics > Power Supply & Distribution > Power Distribution Cabinet & Box > High Voltage Source for DC Pollution Test / DC HV Generator / DC Hipot Test Set
High Voltage Source for DC Pollution Test / DC HV Generator / DC Hipot Test Set
US$ 2,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
FSHV
Model Number:
FSZL-5
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Voltage Source for DC Pollution Test / DC HV Generator / DC Testing SystemUS$ 2,000 - 50,000MOQ: 1 Set -
UHV EHV Source DC High Voltage Generator HV Testing Equipment for Outdoor Field TestUS$ 2,000 - 50,000MOQ: 1 Set
-
UHV EHV DC High Voltage Generator Test System HV Testing Equipment Outdoor FieldUS$ 2,000 - 50,000MOQ: 1 Set
-
DC High Voltage Test Set Direct Current Generator HV Testing EquipmentUS$ 2,000 - 50,000MOQ: 1 Set
-
DC High Voltage Test System Direct Current Generator HV Testing EquipmentUS$ 2,000 - 50,000MOQ: 1 Set
Place of Origin
China
Brand Name
FSHV
Model Number
FSZL-5
High Voltage Source for DC Pollution Test / DC HV Generator / DC Hipot Test Set
Introduction
DC voltage test systems are mainly used to detect the performance of insulation materials under high voltage, long air gap DC discharge performance, insulation performance of large capacitance test objects like power cables, capacitors, generator sets and etc. Also they can measure leakage current of insulation materials and HV apparatuses, and DC HV testing for extra/ultra high voltage DC power transmission equipments.
Features
Features of FSZL series DC voltage test systems,
1. Large output current
2. Small voltage fall
3. Low pulse coefficients
4. High measurement accuracy
5. Automatic polarity switch
6. Automatic tracking and voltage regulating by SCR
7. Rated output voltage can be up to 2400kV
Reference
Indoor type
|
|
|
| ±800kV 25mA | DC HV generator | ±400kV 20mA |
Outdoor type
|
|
| ±1200kV 500mA (for State Grid) | ±1200kV 500mA (for Southern Grid) |
DC Pollution Test
|
|
| ±1000kV 1000mA | ±1500kV 2000mA |
Company Information
We are the leading and earliest manufacturer of high voltage, high current and high power test system in China, provide AC, DC, impulse testing and associated measuring equipment used to electrical application, such as testing project of power cables, power transformers, GIS switchgears, insulators, generators, arresters and etc. And test systems for laboratory, factory and field use are available.
Our factory was founded in 1970, and established R&D center institute of HV testing equipments in 1986, which cooperated with Shanghai Jiaotong University.
We are pleased to announce our quality management system has been approved to ISO 9001 : 2008, so far we have applied more than 58 invention patents.
We have well cooperated with many world famous electrical corporations, like ABB, ALSTOM, SIEMENS, TOSHIBA, HITACHI, HYUNDAI, AE POWERS and etc, also state grids, research institutes, universities and HV testing service providers, we have successfully offered them plenty of high voltage test systems, all well performed.
Our new factory is under construction, which will go into service in 2015, it will become the biggest manufacturer of high voltage testing equipment all over the world.
Contact us
|
Contact person: Roger Chen
Tel: 0086-159-8099 8097
Email: sales#
Website:
|
Send Inquiry to This Supplier
Mr. Roger Chen
Export Manager
Xiamen Fivestar Electric Test Equipment Co., Ltd.
Xiamen, Fujian, China
