China supplier Yoke type track rollers needle bearing NATR45 with axial guidance NATR45 PP
NATR45 Yoke Type Track Rollers are designed to run on all types of tracks and to be used in cam drives, conveyor systems, etc. These bearings have a thick-walled outer ring, which enables them to accommodate high radial loads, while reducing distortion and bending stresses.
The outer ring running surface is crowned as standard. This is beneficial for applications where angular misalignment relative to the track may occur or where edge stresses need to be minimized. With the exception of single row cam rollers, NATR45 Yoke Type Track Rollers are also available with a cylindrical (flat) outer ring running surface.
CHANGZHOU UBT TRACK ROLLERS BEARING DESCRIPTION
| Model NO. | Old NO. | d*D*B | Weight |
| NATR5 | NATD5 | (d×D×B)5×16×12 | 0.014 |
| NATR6 | NATD6 | (d×D×B)6×19×12 | 0.02 |
| NATR8 | NATD8 | (d×D×B)8×24×15 | 0.041 |
| NATR10 | NATD10 | (d×D×B)10×30×15 | 0.064 |
| NATR12 | NATD12 | (d×D×B)12×32×15 | 0.071 |
| NATR15 | NATD15 | (d×D×B)15×35×19 | 0.103 |
| NATR17 | NATD17 | (d×D×B)17×40×21 | 0.144 |
| NATR20 | NATD20 | (d×D×B)20×47×25 | 0.246 |
| NATR25 | NATD25 | (d×D×B)25×52×25 | 0.275 |
| NATR30 | NATD30 | (d×D×B)30×62×29 | 0.47 |
| NATR35 | NATD35 | (d×D×B)35×72×29 | 0.635 |
| NATR40 | NATD40 | (d×D×B)40×80×32 | 0.805 |
| NATR45 | NATD45 | (d×D×B)45×85×32 | 0.91 |
| NATR50 | NATD50 | (d×D×B)50×90×32 | 0.96 |
CHANGZHOU UBT TRACK ROLLERS BEARING
CHANGZHOU UBT TRACK ROLLERS BEARING
1.Neutral packing (neutral plastic bag+ neutral carton+ Plywood/Iron pallets)
2.Custom packing (with logo or barcode according to clients’ requirement)
CHANGZHOU UBT TRACK ROLLERS BEARING
Q: I have a urgent order , and want to find a good supplier in short time ,what should i do ?A: Please send your inquiry to me ,and tell me ,the model ,quantity ,material ,package ,precision ,you need ,i will give you a quick response.
Q: How can i get a price with a discount ?A: Discount according to orders .Bigger order ,less money every bearing will cost ,then discount will be bigger .
Q: I have a trial order ,the quantity is little ,could you manufacturing it for me ?A: Please contact me ,i will tell you the MOQ.If you also need we design the single box for you ,we could make it for you ,and the extra cost of the order will return you by next official order.
Q: I don’t know your factory before ,could you tell me which company you are cooperating now ? I want to get to know more about your factory?A: Sorry ,this is our company regulation :we should not let the information of our customer out ,in the same time ,we also keep your information confidential.If you want to know more information ,you could get some free sample from our factory or visit factory if you have the time .
Q: Does your company could accept D/P or D/A payment terms?A: The payment terms of our company is :30% deposit by T/T or West Union ,70 % balance against the copy of B/L.
Q:Now i have a important order ,the quality must be good ,and my customer will test the goods when receive it ,the quality must be good ,can i trust you ?
A:Our manufacturing factory was founded over 10 years. With so many year professional experience, if you need some certificate to show for your customer, pls inform us. We belive could help u to enlarge your market!
CHANGZHOU UBT TRACK ROLLERS BEARING
CHANGZHOU UBT TRACK ROLLERS BEARING
