New Product of Taishang uv Drying
US$ 2,000 - 5,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Other
Place of Origin:
Guangdong, China
Brand Name:
TISAN
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
uv Dryer of Foshan Taishang Machinery Wood WorkingUS$ 2,000 - 5,000MOQ: 1 Set -
New Drying Machine for Wood and PvcUS$ 2,000 - 5,000MOQ: 1 Set
-
New Style uv Drying Machine of Update FunctionUS$ 2,000 - 5,000MOQ: 1 Set
-
1320# New Stylr uv Drying MachineUS$ 2,000 - 5,000MOQ: 1 Set
-
650#uv Dryer With Two LampUS$ 2,000 - 5,000MOQ: 1 Set
Type
Other
Place of Origin
Guangdong, China
Brand Name
TISAN
Model Number
1420#,1100#,760#
Certification
CE IS9000 TUV
After-sales Service Provided
Engineers available to service machinery overseas
Condition
New
1,This equipment is mainly suitable for paint drying after UV coating of panel-type furniture,cabinet plates,flooring,metal plates and bamboo and wood blinds.
2,This machine uses imported high mercury UV light tubes with adjustable lighting intensity,and meanwhile,it is equipped with high strength capacity and transformers,which has greatly increased the stability of UV light tubes.
3,The conveyor belts adopt stainless steel conveying network equipped with cooling system.And the inside temperature is controlled by the temperature control instrument.
4,It can dry products in a very short time,which greatly reduce the time of coating process;
5,The hardness of the surface of the coated products is improved.And the surface has bright colors.
| Model | TS-760# | TS-1100# | TS-1420# |
| Working width | 650MM | 1000MM | 1320MM |
| Feeding speed | 0-30M/MIN | 0-30M/MIN | 0-30M/MIN |
| Feeding power | 0.75KW | 0.75KW | 0.75KW |
| Tube power | 5KW*2-3 | 5KW*2-3 | 9.6KW*2-3 |
| Fan power | 0.75KW*2-3 | 0.75KW*2-3 | 9.6KW*2-3 |
| Paint type | UV | UV | UV |
| Electric supply | 380V50HZ | 380V50HZ | 380V50HZ |
| Machine dimension | 3000*1060*1860 | 3000*1360*1860 | 3000*1960*1860 |
| Machine weight | 500KG-700KG | 600KG-900KG | 700KG-1100KG |
