Servo UV Printer

Servo UV Printer photo-1
Servo UV Printer photo-2
US$ 2,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
TISAN
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Guangdong, China
Brand Name TISAN
Model Number 760#,1100#,1420#
Usage Other, printing some patterns
Automatic Grade Automatic
Voltage 380V
Dimensions(L*W*H) 3800*1620*1500,3800*1960*1500,3800*2280*1500
Certification CE
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

This equipment adopts chromatic printing with servomotor that the printing is precise.The opelration panel is man-machine

1,This machine adopts chromatic printing with servomotor that the printing is precise.The operation panel is man-machine interface with touch screen and PLC programming.

2,The printing machine adopts the electric intaglio printing principle that it can directly print the pattern on the work piece or through printing rubber roller.

3,It can print patterns on the surface of flat plates,metal plates and PVC etc.It is mainly used in wood and plastic-wood products.

4,The pattern can be printed according to the drawing provided by the customers with a similarity 98.8%.

5,The servomotor controls the speed that it has quick response,high precision and good sychronism.



Model TS-760# TS-1100# TS-1420#
Frontage working width 650MM 1000MM 1320MM
Working height 2-80MM 2-80MM 2-80MM
Feeding speed  0-30M/MIN 0-30M/MIN 0-30M/MIN
Servo power 1.0KW 1.5KW 1.5KW
Paint thickness 0.003-0.2MM 0.003-0.2MM 0.003-0.2MM
Paint container capacity 20L 20L 20L
Air pressure 0.6MPa 0.6MPa 0.6MPa
Electric supply 220V/380V50HZ 220V/380V50HZ 220V/380V50HZ
Machine dimension 3800*1620*1500 3800*1960*1500 3800*2280*1500
Machine weight 2.6T 2.9T

3.2T

Servo UV printerServo UV printer
