SJ55/800 Double Layers oca film laminating machine/Plastic film blowing machine for sale
Use:
It is used for blowing the plastic laminated film of low density polyethylene(LDPE) high density polyethylene(HDPE) and linear density polyethylene( LLDPE)etc.Which are widely used for packing liquid,printed base material,products for export and industrial products,etc.
Characteristics:
1.Double-layers co-exitusion laminated film can prolong the length for preservation of liquid package.
2.The cylinder and the screw stem of the extruder are made of high quality alloy steel with potimum hardness and durable service after precision finishing and nitrogen treatment.
3.The auxiliary machine has a platform working table for making operation easy and is equipped with bubble stabilizing ring.
4.Double rolling and double cutting coiling unit adopts torque motor to keep proper tensions and make rolling even and roll-changing easy.
Main Technical Parameters
| Model | 2SJ-G50 | 2SJ-G55 | 2SJ-G60 | 2SJ-G65 |
| Diameter of Screw | Φ50x2 | Φ55x2 | Φ60x2 | Φ65x2 |
| Reduced Diameter of Film (mm) | 800 | 1000 | 1200 | 1400 |
| Single-face Thickness of Film (mm) | 0.015-0.10 | 0.015-0.10 | 0.015-0.10 | 0.015-0.10 |
| Max.Output (kg/h) | 40 | 65 | 80 | 100 |
| L/D | 28:1 | 28:1 | 28:1 | 28:1 |
| Power of Main Motor (kw) | 11x2 | 15x2 | 18.5-x2 | 20x2 |
| Power of Traction Motor(kw) | 1.1 | 1.1 | 1.5 | 1.5 |
| Heating Power (kw) | 26 | 30 | 42 | 50 |
| Outline Diameter (LxWxH) (mm) | 4200x2200x4000 | 4600x2400x4600 | 5000x2800x4600 | 6500x2500x4600 |
| Weight (TON) | 4T | 5T | 6T | 7T |
Main Constructions of Film Blowing Machine:
1. Extrusion Machine
2. Three Way Connecter
3. Die Set
4. Cooling Ring
5. Down Frame
6. Traction System
7. Winder
Detailed Pictures
Niingbo Yoonstar Imp. and Exp. Co.,Ltd. is a professional manufacturer of plastic machinery company.
Main Product: multi-layer coextrusion machine,film blowing machine,printing machine and bag making machine and other accerrory machinery.
We work on the quality of the first faith-based service of customer focus,production according to the customers requires,highly praised in the world,we have the right of imports and exports,the products have been sold all of the world.Known in the world,Reliavle by the customer.
Yoonstar is willing the coorperation with you making briliant future.
