SJ-45x2x600 4 color Printing Machine/Double Colors LDPE/HDPE/LLDPE Film Blowing Machine for Sale
Characteristics:
It is used for blowing various low density polyethylene (LDPE) and high density polyethylene(HDPE) color striped plastic film,etc,which are widely used for packing food,fruit,garments,textile,daily necessoriesand other civil and industial products.The cylinder and the screw stem of Model SJ-45Dx2 extruder are made of high quality alloy steel with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment.
600 anxiliary machine can be freely adjusted within the limits 600mm according to the technological requirements of different materials,and has been fitted wtih a plug in plate mechinaism for making vest bag.The coiling unit adopts torque motor to keep proper tension and make rolling even and roll changing easy.
Main Technical Parameters
| Model | 45x2 | 50x2 | 55x2 |
| Diameter of Screw | Φ45x2 | Φ50x2 | Φ55x2 |
| Reduced Diameter of Film (mm) | 100-600 | 200-800 | 300-1000 |
| Single-face Thickness of Film (mm) | 0.01-0.10 | 0.01-0.10 | 0.01-0.10 |
| Max.Output (kg/h) | 35 | 50 | 65 |
| L/D | 26:1 | 26:1 | 26:1 |
| Power of Main Motor (kw) | 15 | 18.5 | 22 |
| Power of Traction Motor(kw) | 1.1 | 1.1 | 1.5 |
| Heating Power (kw) | 15 | 18 | 25 |
| Outline Diameter (LxWxH) (mm) | 4800x1900x4100 | 5500x2100x4700 | 6500x2300x4900 |
| Weight (TON) | 2T | 2.5T | 3T |
Main Constructions of Film Blowing Machine:
1. Extrusion Machine
2. Three Way Connecter
3. Die Set
4. Cooling Ring
5. Down Frame
6. Traction System
7. Winder
Detailed Pictures
Niingbo Yoonstar Imp. and Exp. Co.,Ltd. is a professional manufacturer of plastic machinery company.
Main Product: multi-layer coextrusion machine,film blowing machine,printing machine and bag making machine and other accerrory machinery.
We work on the quality of the first faith-based service of customer focus,production according to the customers requires,highly praised in the world,we have the right of imports and exports,the products have been sold all of the world.Known in the world,Reliavle by the customer.
Yoonstar is willing the coorperation with you making briliant future.
