7 Inch TFT LCD Monitor Car&Vehicle Rear View Camera System,
Truck Bus Wireless Camera and Camera Reverse with Sound.
wireless Car Rearview Waterproof Camera Back up night vision camera wireless truck rearview camera
This product consists of 1 wireless color TFT LCD screen car rear view monitor and 1 wireless back up camera with 18pcs IR LEDs. It provides wide view angle for reversing and improves safety for the driver. In addition to its basic functions, it can also work perfectly with car DVD, VCD, STB, satellite receiver and other video equipment, suitable for buses, trucks and other special vehicles.
Features:
- 7" digital color TFT LCD screen
- From the perspective of range - 50 degrees, the next 70 degrees, 70 degrees left -, right - 70 degrees
- Automatic modulation recognition system PAL / NTSC
- OSD control the brightness, contrast, color, volume, mode, flip, languages(English, German, French, Spanish, Portuguese, Italy, Holland, simplified Chinese)
- Built-in 2.4GHz wireless transmitter and receiver with an effective distance of 100 meters
- 2 way video input
- Aluminum alloy material shell, plug-in design
- 18 IR LEDs camera supports night vision
Monitor:
Function of keys:
- "V1/V2": AV1/AV2 video quick switch, press the key to switch the cycle of AV1/AV2 video picture
- "MENU": Press the key can circularly open menu
- "-": Select the down regulating parameters in the menu
- "+": Select the up regulating parameters in the menu
- "POWER": On / Off
Connection Method: Red wire is connected to the +12V / 24V DC, black wire to the +12 / 24(GND), green wire to the reversing forced wire, AV plug to camera(AV2), AV socket to DVD VIDEO(AV1)
Screen Size: 7 inches
Display Component: Color TFT LCD
LED Backlight Brightness: 300 cd/m2
Screen Ratio: 16:9
Pixel: 800 x 480
System: PAL / NTSC system(auto switch)
Contrast Ratio: 1000:1
Power Requirement: DC 12V / 24V
Power: <=5W
Current:<=450mA
Seismic Level: 4G
Reception: <=100 meters in the open air
Video: 2 way video input
Rear View: V2 auto reverse when trigger activated
Operate Mode: Key operation and remote control
Working Temperature: -10C~+60C
Storage Temperature: -20C~+70C
Dimension: 172mm x 113mm x 23mm
Net Weight: 287g
Camera:
Image Sensor: COMS
Definition: 480 TVL
Scanning System: 2:1 interface
Illumination: 0.5Lux, IR ON
Image Angle: 120 degrees
IR LEDs: 18pcs
Image: Mirror / Preimage optional
Video Format: PAL / NTSC
Video Output: 1.0vp-p, 75
Electronic Shutter: 1/60~1/10,000 second
Gama: 0.45
S/N Ration: > 48 db
Dustproof & Waterproof Level: IP67/68
Seismic Level: 4G
Reception: < = 100 meters in the open air
Power Requirement: DC 12V / 24V
Power: < = 3W
Current: < = 250mA
Working Temperature: -10C~+60C
Storage Temperature: -20C~+70C
Dimension: 95mm x 75mm x 50mm
Net Weight: 280g
General:
Package Dimension: 230mm x 180mm x 125mm
Package Weight: 945g
After Sales Service: 1 Year Warranty
EPC_CMO_398
Package Include:
1 x Monitor
1 x Camera
1 x Bracket
1 x AV Cable
1 x Remote Control
2 x Antenna
3 x Screw
1 x User Manual
