Specifications
Air to water heat pump1.heating/cooling
2.heating capacity:41KW
3.Automatic defrost
4.CE,Rohs
Commercial Air source heat pump water chiller unit cooling/heating
| Model | MACHRW | 080ZB/S(02) | 100ZB/S(02) | 120ZB/S(02) |
| Rated Output Water | L/h | 540 | 755 | 885 |
| Rated Cooling Capacity | kW | 20.0 | 25.0 | 30.0 |
| BTU/h | 68300 | 85300 | 102400 | |
| Rated Input Power(Cooling) | kW | 6.30 | 7.90 | 9.40 |
| Rated Input Current(Cooling) | A | 11.1 | 13.9 | 16.5 |
| Rated Heating Capacity | kW | 24.0 | 30.0 | 36.0 |
| BTU/h | 81900 | 102400 | 122900 | |
| Rated Input Power(Heating) | kW | 7.10 | 8.90 | 10.60 |
| Rated Input Current(Heating) | A | 12.5 | 15.6 | 18.6 |
| Power Supply | V/PH/Hz | 380/3/50 | 380/3/50 | 380/3/50 |
| Compressor | Scroll | Scroll | Scroll | |
| Compressor Qty | 2 | 2 | 2 | |
| Fan Qty | 2 | 2 | 2 | |
| Noise | dB(A) | 58 | 58 | 58 |
| Hot water side | ||||
| Water Connection | inch | 1-1/4 | 1-1/4 | 1-1/4 |
| Water Flow Volume | m3/h | 7-8 | 7-8 | 7-8 |
| Air condition side | ||||
| Water Connection | inch | 1-1/4 | 1-1/4 | 1-1/4 |
| Water Flow Volume | m3/h | 6-7 | 6-7 | 6-7 |
| Fan Direction | Vertical | Vertical | Vertical | |
| Refrigerant Gas Type | R410a | |||
| Main Unit Net Dimensions(L/M/H) | mm | 1450/730/1060 | 1450/730/1260 | 1450/730/1260 |
| Main Unit Shipping Dimensions(L/M/H) | mm | 1545/780/1110 | 1545/780/1310 | 1545/780/1310 |
| Net Weight | kg | 250 | 265 | 300 |
| Shipping Weight | kg | 275 | 290 | 325 |
Working principle:
Heat pump water heater is a device which can efficiently collector and transfer heat.
Its function is to absorb the heat from the air or low-temperature water as well as to convert its own operating electric power into heat, then to transfer the heat to high-temperature environment.
Air source hot water heat pump(instant & circulating)
instant heating
1.,the cop is more than 4.0, heat the water directly to 60
2.the water temperature set freely
outlet water temperature constant, advanced water control system, heat the water to 60 diretly. Adjustable outlet water temperature.Adjust the water temperature(45-60)according to the need.
3.once adjusted, the unit outlet water temperature would be fixed on the set temperature.
4.the unit runs more stable, reliable without EHV(exceed high voltage).
5.water tank volume seleted freely, more practical
6.water and electricity system is completely separated, assure using safely
7.Intelligent control
With automatic filling water,water level control,defrost, power-fail memory,charge adjustment system,with booking timed heating,LCD display remote control and clock.
circulating
1:the cop is more than 4.0, more efficient
2.Meet a large consumption,stable and reliable hotwater output and performance,high energy efficiency ratio,constant water tank temperature to ensure comfortable use.
3. the unit runs more stable, reliable without EHV(exceed high voltage)
Debase efficiently the attenuation of the heat exchange rate,assure hot water capacity.Adopting high efficient tube heat exchanger, waster rate is greatly reduced, long-term and stable operation.
4.water tank volume seleted freely, more practical
5.water and electricity system is completely separated, assure using safely
6.Intelligent control
With automatic filling water,water level control,defrost, power-fail memory,charge adjustment system,with booking timed heating,LCD display remote control and clock.
