air to water heat pump,heat pump water heater,domestic hot water heat pump,hot water heating heat pump

Specifications

1.R410a/407c
2.built in WILO water pump
3.heat exchanger 316ss material plate.
4. 3 way valve controller
5. sloar contro

Model	MAHRW	010WAB/P	015WAB/P	020WAB/P	025WAB/P	030WAB/P	035WAB/P	040WAB/P	040WAB/PS	045WAB/PS	050WAB/P	050WAB/PS	060WAB/PS
Rated Output Water	L/h	80	105	140	175	205	230	270	270	355	380	380	445
Rated Heating Capacity	kW	3.7	4.8	6.5	8.0	9.5	10.5	12.5	12.5	16.5	17.5	17.5	20.5
	BTU/h	12700	16400	22200	27300	32500	35900	42700	42700	56300	59800	59800	70000
Rated Input Power	kW	1.00	1.30	1.80	2.20	2.65	2.90	3.45	3.45	4.55	4.85	4.85	5.70
Rated Input Current	A	4.5	5.9	8.2	10.0	12.0	13.2	15.7	6.1	8.0	22.0	8.5	10.0
Rated Temp.Of Water Output	°C	55	55	55	55	55	55	55	55	55	55	55	55
Max.Temp.Of Water Output	°C	60	60	60	60	60	60	60	60	60	60	60	60
Power Supply	V/PH/Hz	220/1/50	220/1/50	220/1/50	220/1/50	220/1/50	220/1/50	220/1/50	380/3/50	380/3/50	220/3/50	380/3/50	380/3/50
Noise	dB(A)	48	48	48	48	50	54	54	54	54	54	54	54
Compressor		Rotary	Rotary	Rotary	Rotary	Rotary	Rotary	Rotary	Scroll	Scroll	Scroll	Scroll	Scroll
Compressor Qty		1	1	1	1	1	1	1	1	1	1	1	1
Fan Qty		1	1	1	1	1	1	1	1	1	2	2	2
Working Temp.Range	°C	-15~45	-15~45	-15~45	-15~45	-15~45	-15~45	-15~45	-15~45	-15~45	-15~45	-15~45	-15~45
Fan Direction		horizontal	horizontal	horizontal	horizontal	horizontal	horizontal	horizontal	horizontal	horizontal	horizontal	horizontal	horizontal
Refrigerant Gas Type		R410a
Water Flow Volume	m3/h	3	3	4	4	4	4	5	5	5	6	6	6
Circulating Water Out/inlet	inch	3/4	3/4	3/4	3/4	1	1	1	1	1	1	1	1
Recyching Water Inlet	inch	/	/	/	/	3/4	3/4	3/4	3/4	3/4	3/4	3/4	3/4
Main Unit Net Dimensions(L/M/H)	mm	930/350/550	930/350/550	1005/360/620	1005/360/620	1115/470/700	1115/470/700	1115/470/945	1115/470/945	1115/470/945	1115/470/1250	1115/470/1250	1115/470/1250
Main Unit Shipping Dimensions(L/M/H)	mm	1035/395/585	1035/395/585	1095/405/650	1095/405/650	1205/525/725	1205/525/725	1205/525/975	1205/525/975	1205/525/975	1205/525/1280	1205/525/1280	1205/525/1280
Net Weight	kg	30	35	41	50	65	70	85	85	90	112	112	115
Shipping Weight	kg	35	38	44	55	80	85	100	100	105	127	127	130

1. High-efficient and energy saving

Using energy efficient compressors and heat exchanger of 316 stainless steel material welded  plate and S&C.Comprehensive energy consumption is only65% of  the solar energy water heater,25% of electric  water heater, considerable cost to save,initial investment to withdraw in short-term.

2. Safe and reliable

Hydropower isolation, no produce exhaust. Prevent leakage and gas poisoning. Integration design,  system completely welding airtight,without refrigerant pipe connections, more simple and reliable installation.

3. Flexible configuration

The unit and tank flexible configuration.Different water tank to choose,pressure or open type connected to meet the different demands of clients.

4. Environment Friendly

Using refrigerant 410A, no damage,environment friendly.

5. Three-core design(Combination with three heat sources)

Heat pump, electric auxiliary heat and solar integrated together (optional). When sunny, heat  pump does not work, otherwise, pump start-up. Super energy-saving and supply hot water in any weather.

6. Advanced technologies

Built-in WILO water pump , with functions of outage memory , automatic water filling and  water level control , automatic detection filling pressure and pressurization control , with the   protections of  water flow, compressor discharge , system

pressure, power supply fault and lack of phase,freeze protection, automatic unloading start and automatic defrost.

7. Automatic cleaning

Patent  technology, unit cleans finned automaticly every 72 hours,  air heat exchanger will be  the most efficient  working, avoiding artificial maintenance.

8. Simple operation

Intelligent design, LCD display,simple operation,free setting during 30°C~60°C and cycle timing set on/off freely.

9. Quiet running

Using efficient , low-noise rotary , closed  scroll compressors and low-noise fan,ensure quiet running.

10. Working environment

Applicable to -15°C~45°C  the outdoor harsh environment temperature, all-weather work.

11. Wide application

Widely used for room radiant , floor heating , schools , factories , apartments , sauna , SPA  association , beauty salon,fitness center,guesthouse,hotel, hospital, senior residential, swimming  poo l, factories, farms, greenhouse production process etc, can replace the fuel gas boiler and heating boilers, water equipment etc.
