Help CenterMacon Geothermal Heat Pump DC Inverter Water to Water Heat Pump With CE/SAA/CCC
Related Products
-
DC Inverter Water to Water Heat PumpUS$ 600 - 3,000MOQ: 1 Set -
DC Inverter Water to Water Heat PumpUS$ 600 - 3,000MOQ: 1 Set
-
10Kw DC Inverter Water to Water Heat PumpUS$ 600 - 30,000MOQ: 1 Set
-
2012 MACON 16Kw DC Inverter Ground Source Heat Pump,DC Inverter Geothermal Cooling Heating Hot Water Heat PumpUS$ 600 - 3,000MOQ: 1 Set
-
CE ETL MACON 25Kw DC Inverter Sanyo Compressor Ground Source Geothermal Air Coditioning & Heating Heat Pump Plate ExchangerUS$ 600 - 30,000MOQ: 1 Set
Ground source heat pump
COP:4.15-5.5
Certification: CE,CCC
Refrigerant: 410a
| Model | MWCHRW(S) | 015Z/(B02) | 020Z/(B02) | 050Z/(B02) | 050Z/S(B02) | 080Z/S(B02) | 100Z/S(B02) |
| Rated Output Water | L/h | 95 | 120 | 300 | 300 | 500 | 625 |
| Rated Cooling Capacity | KW | 3.9 | 5.2 | 13.0 | 13.0 | 20.8 | 26.0 |
| BUT/h | 13300 | 17700 | 44400 | 44400 | 71000 | 88700 | |
| Rated Input Power(Cooling) | KW | 0.84 | 1.12 | 2.80 | 2.80 | 4.47 | 5.59 |
| Rated Input Current(Cooling) | A | 3.8 | 5.1 | 12.7 | 4.2 | 6.8 | 8.5 |
| Rated Heating Capacity1 | KW | 4.4 | 5.6 | 14.5 | 14.5 | 23.2 | 29.0 |
| BTU/h | 15100 | 19200 | 49500 | 49500 | 79200 | 99000 | |
| COP1 | W/W | 4.2 | 4.2 | 4.2 | 4.2 | 4.2 | 4.2 |
| Rated Input Power(Heating)1 | KW | 1.05 | 1.33 | 3.45 | 3.45 | 5.52 | 6.90 |
| Rated Input Current(Heating)1 | A | 4.8 | 6.1 | 15.7 | 5.2 | 8.4 | 10.5 |
| Rated Heating Capacity2 | KW | 4.8 | 6.4 | 16.0 | 16.0 | 25.6 | 32.0 |
| BTU/h | 16400 | 21900 | 54600 | 54600 | 87300 | 109200 | |
| COP2 | W/W | 5.50 | 5.50 | 5.50 | 5.50 | 5.50 | 5.50 |
| Rated Input Power(Heating)2 | KW | 0.87 | 1.16 | 2.91 | 2.91 | 4.65 | 5.82 |
| Rated Input Current(Heating)2 | A | 4.0 | 5.3 | 13.2 | 4.4 | 7.1 | 8.8 |
| Rated Heating Capacity3 | KW | 4.5 | 6.0 | 15.0 | 15.0 | 24.0 | 30.0 |
| BTU/h | 15400 | 20500 | 51200 | 51200 | 81900 | 102400 | |
| COP3 | W/W | 4.15 | 4.15 | 4.15 | 4.15 | 4.15 | 4.15 |
| Rated Input Power(Heating)3 | KW | 1.08 | 1.45 | 3.61 | 3.61 | 5.78 | 7.23 |
| Rated Input Current(Heating)3 | A | 4.9 | 6.6 | 16.4 | 5.5 | 8.8 | 11.0 |
| Power Supply | V/PH/Hz | 220/1/50 | 220/1/50 | 220/1/50 | 380/3/50 | 380/3/50 | 380/3/50 |
| Compressor | Rotary | Rotary | Rotary | Scroll | Scroll | Scroll | |
| Noise | dB(A) | 45 | 46 | 50 | 50 | 52 | 52 |
| Hot Water Side | |||||||
| Water Out let/Water In let | inch | 3/4" | 3/4" | 1" | 1" | 2" | 2" |
| Water Flow Volume | m3/h | 0.76 | 0.96 | 2.49 | 2.49 | 3.99 | 4.99 |
| Air Condition Side | |||||||
| Water Out let/Water In let | inch | 3/4" | 3/4" | 1" | 1" | 2" | 2" |
| Water Flow Volume | m3/h | 0.83 | 1.10 | 2.75 | 2.75 | 4.40 | 5.50 |
| Hot source Side | |||||||
| Water Out let/Water In let | inch | 3/4" | 3/4" | 1" | 1" | 2" | 2" |
| Water Flow Volume | m3/h | 0.83 | 1.10 | 2.75 | 2.75 | 4.40 | 5.50 |
| Refrigerant type | R410a | ||||||
| Unit Net Dimensions(L/M/H) | mm | 670/600/760 | 670/600/760 | 670/600/760 | 670/600/760 | 1230/730/800 | 1230/730/800 |
| Unit Shipping Dimensions (L/M/H) | mm | 720/650/860 | 720/650/860 | 720/650/860 | 720/650/860 | 1280/790/920 | 1280/790/920 |
| Net Weight | kg | 65 | 70 | 100 | 110 | 310 | 320 |
| Shipping Weight | kg | 70 | 75 | 105 | 115 | 340 | 350 |
| Note: (1)Cooling :Air condition side inlet/outlet :12℃/7℃,Hot source side inlet/outlet:30℃/35℃; (2)1Heating:Hot water side inlet/outlet :15℃/55℃,Hot source side inlet/outlet:10℃/-; (3)2Heating:Air condition side inlet/outlet :30℃/35℃,Hot source side inlet/outlet:10℃/-; (4)3Heating:Air condition side inlet/outlet:40℃/45℃,Hot source side inlet/outlet:10℃/-; | |||||||
1.Wide application
Widely used in hotels,restaurants,apartment houses, villas, factories and schools, sauna, bathroom, SPA association, beauty salon, fitness center, swimming pool, aquaculture, etc to applicate with various terminal equipment (fan coil, floor heating, radiators, temperature-holder tank etc.), combining indoor luxury decoration, maximizing satisfy user's requirements and comfortable. The modular structure is suitable for various sizes of engineering, office buildings, hotels, restaurants, cinema, shopping plaza, gymnasium, hospital etc., as the best choice of various public places.
2.five modes
Cooling, heating, hot water ,cooling and hot water,heating and hot water.
3.High efficiency and energy saving
Using energy efficient scroll compressors, 316 stainless steel material welded plate heat exchanger. Comprehensive energy consumption is only65% of the solar energy water heater,25% of electric water heater. When it is hot water and cold water, the COP will be more than 6.
4.Flexible configuration
The unit and tank flexible configuration.A different water tank to choose, pressure or open type connected to meet the different demands of clients.
5.Flexible installation position
Host appearance, compact tank to small occupation space for installation, conduit length of flexible connection
6.Hot water circulation heat straight
55 degrees hot water heated one-time and got directly to use, improve comfort of water using and stable of unit. When stop to use water in a long time and the water temperature drops, unit will heat cyclely and automaticly.
7.Dual-core design
Heat pump, electric auxiliary heat integration together, super energy-saving and hot water in all-weather.
8.The advanced control technology of water
WILO water pump built-in, with water flow protection, automatic filling and water level control, automatic water pressure test, hydrating pressurization control and Automatic constant temperature adjustment.
9.Integrated design, multi-protect and reliable
Integration design, system sealed welding completely, just conduit connections, without refrigerant pipe connections, simple and reliable connection installed. built-in protections of hot water flow and air flow, compressor exhaust temperature, high and low pressure compressor, compressors flow and power fault phase, power supply fault and lack of phase ,freeze protection, automatic defrost and automatic load adjusting etc built-in. Multiple protections.
10.Environment Friendly
Using refrigerant 410A, no damage, environment friendly.
11.Multi-source design
Air source , ground source, solar and electric auxiliary heat integrated together (optional), super energy, which can meet all-weather hot water supply.
12.Simple operation
Intelligent design, LCD display, simple operation, free setting during 8 ° c - 60° c and cycle timing set on/off freely.
13.Quiet running
Using efficient, low-noise rotary, closed scroll compressors and low-noise fan, ensure quiet running
14. Multi-protection
Unit with phase sequence, water flow, freezing, high, low voltage and over-temperature, over current of compress or protection and so on.
15. multi-purpose, complete function
With function of refrigerating, heating and hot water, provide hot water freely under the refrigeration condition.
Our Service
1) MACON can supply OEM service for customers.
2) Produce heat pump according to customer's special demands.
3) Supply spare parts according to order quantity.
4) Warranty: 1% free spare parts
Certificate
Obtain certificates CE, ROHS, SAA, Water mark, Standard mark, C- tick, ETL, CCC, and pass ISO9001:2000
FAQ Frequently Asked Questions
1. Can I use our own brand logo on the products?
Yes. We provide OEM/ODM service to our customers.
2. Can you do special product for us?
Yes. We have professional engineers having rich experience in heat pump design and manufacturing.
3. What is your terms of delivery?
We accept EXW, FOB, CIF, etc.
4. What is your payment terms?
-For sample order: T/T 100%
-For container order: T/T 30% deposit, T/T 70% before shipment or L/C
5. What about warranty?
We usually provide 1% free spare parts according to your order quantity.
