FiberHome Fengine B2161-2E14TX Converter

Name: FiberHome Fengine B2161-2E14TX Converter
Brand: fiberhome
SKU: 113218545

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hubei, China

Brand Name:

fiberhome

Model Number:

Fengine B2161-2E14TX

Wuhan Fiberhome International Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

wuhan

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hubei, China

Brand Name fiberhome

Model Number Fengine B2161-2E14TX

Specifications

FiberHome Fengine B2161-2E14TX Converter
support four network devices or other devices for remote centralized management

Product Description

Features	Description
E1 Interface
Number of Ports	2
Interface Standard	G.703, G.704
Line Impedance and Connector	120Ω, balanced, RJ-45 75Ω, unbalanced, BNC
Data Rate and Line Code	2.048 Mb/s,HDB3
LLF	Auto disable Ethernet ports when E1 ports link down
Ethernet Interface
Number of Ports	4
Interface Type	10/100Base-TX or 100Base-FX
Compliance	Relevant sections of IEEE 802.3
Data Rate	Electrical: 10/100Mbps
Max Frame Size	2047bytes
Connector	Electrical: RJ-45
Electrical Cable Type	Cat.5
Line Protection	Built-in 1.5 KV Magnetic Isolation Protection, 6KV/42Ω surge protection
Encapsulation Protocols
GFP-F	ITU-T G.8040, G.7041/Y.1303
LCAS	ITU-T G.7042
Management Ports
Console Port Interface standard	Connector: RJ-45 Standard: PC serial interface
Other Features
Dimension (w* d* h)	210x142x41mm
Working condition	Operating Temperature: 0 to 50°C Storage Temperature: -40 to 70°C Ambient Relative Humidity: 10 to 95% (non-condensing)
Power supply	AC:100-240VAC(±10%),50/60Hz DC:-48VDC(-36 ~ -72VDC) AD: AC/DC dual power supply universal input
Weight	0.8Kg
Housing	Metal
