Fengine S2800 24 port Optical Ethernet Switch
Fengine S2800 series intelligent fast Ethernet switches (S2800) are leading Layer 2 manageable edge devices developed by FiberHome for service providers and enterprise networks. It provides 10/100 Mbps downlink and 1000 Mbps uplink Ethernet ports and can be deployed in various scenarios, such as access layer for 100 Mbps-to-desktop in enterprise networks, metropolitan area networks and various industry networks to connect end users or aggregate client devices with 10/100 Mbps connections. Combining the 10/100M and Power over Ethernet (PoE), Fengine S2800 enhances end user’s connection convenience by enabling applications such as IP telephony, wireless and video. With improved operational excellence, highly secure business operations, improved sustainability and an enhanced quality of experience, the S2800 helps customers build networks with lower OPEX & CAPEX.
Main Features
♥ Excellent Security Control
♥ Comprehensive Reliability Mechanisms
♥ Superior Quality of Service
♥ Enhanced PoE Function
♥ Fan-free & Energy Saving Design
♥ Surge Protection
♥ Easy Management & Maintenance
| Features | S2800-26T-C |
| Ports | 24*10/100Base-Tx 2*GE Combo |
| Throughput | 6.55 Mpps |
| Forwarding bandwidth | 8.8 Gbps |
| Switching bandwidth | 32 Gbps |
| MAC address table | 16 K |
| VLAN | 4k VLANs(IEEE 802.1Q) QinQ, selective QinQ 1:1 & N:1 VLAN mapping |
| TRUNK | 14 groups, each trunk group containing up to 8 ports |
| Multicast | IGMP Snooping,IGMP proxy Multicast VLAN |
| Reliability | STP(IEEE 802.1d), RSTP(IEEE 802.1w), MSTP(IEEE 802.1s) R-link |
| Surge protection | 6KV surge protection |
| QoS/ACL | 802.1p priorities with eight queues of different priorities on each port Flexible scheduling algorithms, including SP, WRR, SP+WRR Egress and Ingress rate limiting with granularity at 64Kbps Packet filtering at Layer 2 to Layer 4, filtering out invalid frames based on source MAC address, destination MAC address, source IP address, destination IP address, TCP/UDP port number, protocol type and VLAN ID |
| Security | DHCP Snooping Option 82 Limit on the number of learned MAC addresses 802.1X authentication, RADIUS authentication Binding of MAC address and interface IP Source Guard CPU protection Storm control |
| Management & maintenance | Port mirroring SNMP, configuration via Web, CLI, Telnet, Console port, Upgrade via FTP Fengine Wview GUI management platform based on SNMP SSH v2.0 Cluster network management Port loopback detection |
| Operating environment | Operation temperature: 0℃ to 50℃ Relative humidity:10%-90% (non-condensing) |
| Input voltage | AC: Rated voltage range:100V to 240V AC, 50/60Hz Maximum voltage range:90V to 264V AC, 50/60Hz DC: Rated voltage range: -48V to -60V DC Max voltage range: -36V to -72V DC |
| Dimensions (W×D×H)mm | 440×192×44 |
| Power consumption | <15.6W |
| Weight | <2.1 kg |
