Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Cell > A.290W Poly Solar Panel With CE Certificate

A.290W Poly Solar Panel With CE Certificate

Name: A.290W Poly Solar Panel With CE Certificate
Brand: RISUN
SKU: 113215411
Availability: InStock

US$ 0.48 - 0.58 MOQ: 1 Piece

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

RISUN

Model Number:

RSM72-156P/290W

Risun Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name RISUN

Model Number RSM72-156P/290W

Material Polycrystalline Silicon

Size 1950*990*50mm

Number of Cells 72

Max. Power 290w

Specifications

290W Poly Solar Panel with CE certificate
1) high efficency solar panel
2) easy to install panel
3) stand heavy rain and sno

290W Poly Solar Panel with CE certificate

Detailed information:

Solar Panel Parameters	RSM72-156P/290W
Optimized working voltage	36.40V
Optimized working current	7.96A
Open circuit voltage	44.4V
Short circuit current	8.43A
Nominal power	290W
Module efficiency	15.00%
Operating temperature	-40°C to+85°C
Maximum system voltage	1000VDC(IEC)/600VDC(UL)
Series fuse rated value	20A
Power tolerance	±3%
Cell specification	156×156mm (6inch)
Arrangement quantity	72(6×12)
Solar panel dimension	195099050
Weight	27.0kg
Glass specification	3.2mm(0.13inch) tempered glass
Frame	Anodised aluminium alloy
Rated operating temperature	45±2°C
Pmax temperature parameter	-(0.48±0.05)%/°C
Voc temperature coefficient:	-(0.34±0.1)%/°C
Isc temperature coefficient	0.04±0.01%/°C
Dimension of pallet	200011501150mm
Quantity in a 20’ container	14pallet; 21pcs/pallet;294pcs
Quantity in a 40’ container	28pallet;21pcs/pallet;588pcs
Notic:Data under standard testing condition (STC):1000W/m²,AM1.5,25°C.
