High Efficiency Mono 250w Solar Panel With TUV ISO CE Certified
US$ 0.48 - 0.58
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Risun, Risun
Model Number:
RSM60-156M/250W
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sell Price per Watt Solar Panels of 270w Solar PanelUS$ 0.48 - 0.58MOQ: 1 Piece -
A.Hot Sale 290w Poly Solar Panel With High EfficiencyUS$ 0.48 - 0.6MOQ: 1 Piece
-
240W 250W 260W Mono Solar PanelUS$ 0.48 - 0.58MOQ: 1 Piece
-
240w Mono Solar Panel With Reasonable Price in ChinaUS$ 0.48 - 0.58MOQ: 1 Piece
-
Hot Sale 270W Poly Solar Panel Manufacturer With TUV IEC CertificateUS$ 0.48 - 0.58MOQ: 1 Piece
Place of Origin
Jiangsu, China
Brand Name
Risun, Risun
Model Number
RSM60-156M/250W
Material
Monocrystalline Silicon
Size
1650*992*45
Number of Cells
60
Max. Power
250
Specifications
250W Mono Solar Panel Specifications1.Quality A
2.Offer OEM service
3.Efficiency is above 17%
4.CE certificate
250Mono Solar Panel, Solar Panel, Solar Module Tehnical Data
| Electrical Data | |||
| MONO | RSM60-156M/250W | ||
| Nominal peak power(Pmax) | 250Wp | ||
| Maximum power voltage(Vmp) | 30.96V | ||
| Maximum power current(Imp) | 8.08A | ||
| Short-circuit current(Isc) | 8.62A | ||
| Open circuit voltage(Voc) | 37.92V | ||
| Optimized cell efficiency(η) | 18.00% | ||
| Power tolerance: ±3% | |||
| Limits | |||
| Operating temperature | -40°C to +85°C | ||
| Maximum system voltage | 1000VDC | ||
| Temperature and Coefficients | |||
| NOCT | 48°C±2°C | ||
| Current temperature coefficient | %/°C | 0.037 | |
| Voltage temperature coefficient | %/°C | -0.34 | |
| Power temperature coefficient | %/°C | -0.48 | |
| NOCT:Nominal Operation Cell Temperature | |||
| Additional Data | |||
| Number of cells and type of connection | 72,serial connection | ||
| Dimensions | 1950*990*50 | ||
| Net weight | 26.0kgs/pc | ||
| Gross weight | 623kgs/ctn(28pcs/ctn) 46kgs/ctn(2pcs/ctn) | ||
| STC: Irradiance of 1000W /m2, Air Mass of 1.5, Cell Temperature of 25°C | |||
|
Guaranteed Power Output Warranted Tolerance: ±5% |
15 year:90% of its nominal power rating | ||
| 25 year:80% of its nominal power rating | |||
| Impact Resistance | Can bear the force that is generated by one 227g | ||
| steel ball fall down from 1m height | |||
| Warranty period | 10 years:Materials and workmanship defects | ||
| Certificates | CE,ISO,IEC61215&61730(TUV),UL1703/CSA,MCS | ||
| Cells | Monocrystalline silicon photovoltaic cell | ||
Advantages:
Lower price but constant good quality:
1. Excellent A grade solar cell from JA solar or our own lab;
2. Excellent backsheet from SFC, 3M;
3. EVA from Bridgestone;
4. Junction box with UL and TUV listed, IP65;
5. High transmission low iron tempered glass;
6. Solar panels with TUV, IEC, CE, ISO9001, ISO14001, CEC marked and ETL, MCS in processing;
7. Warranty:
(1)5years quality assurance resulted from design, material and workmanship;
(2)Not less than 90% power output within 10years;
(3)Not less than 80%power output within 25years;
(4)Third-party insurance(Certificate Of Products Quality Warranty and Certificate Of Products Liability Insurance).
Any question please ask me feel free, and please add me Skype:.0724
