Specifications
300W Mono Solar Panel1) high efficency
2) easy to install
3) stand heavy rain and snow
4) lower price
|
Type Silicon Parameters |
300W |
|
Mono-crystalline silicon | ||
Maximum Power (Pmax) |
W |
175 |
Power Tolerance |
|
±5% |
Maximum Power voltage (Vmp) |
V |
35.40 |
Maximum Power current (Imp) |
A |
8.47 |
Open circuit voltage (Voc) |
V |
44.40 |
Short circuit current (Isc) |
A |
10.17 |
Size of module (Length and Width) |
1950*990*50 |
|
Frame (type, material and thickness) |
Anodized Alu. alloy frame, 46 mm thickness |
|
Quantity of cells |
72 pcs (6x12) |
|
Cell Size |
125 x 125 mm |
|
Weight |
15.0 Kg |
|
Type of junction box |
IP65 |
|
Cable type |
2 PfG 1169, 4mm² |
|
Maximum system voltage |
1000V |
|
Temperature coefficient of Isc |
+0.05%/ |
|
Temperature coefficient of Voc |
-0.34%/ |
|
Temperature coefficient of power |
-0.5%/ |
|
NOCT (Nominal operating cell temperature) |
47(+2) |
|
Insulation |
>=100MOhm |
|
Voltage Standoff |
AC2000V, DC3000V |
|
Wind Bearing |
60m/s(200kg/sq.m) |
|
Impact Resistance Hail Impact Test |
227g steel ball fall down from 1m height |
|
Glass |
high transmission, low iron, tempered glass 3.2 mm |
|
Cell Efficiency |
16.33% |
|
Module Efficiency |
13.71% |
|
Characteristics:
1) Manufactured according to international quality and Environment Management
System (ISO9001, ISO14001)
2) High efficiency crystalline silicon solar cells
3) High transmission Low iron tempered glass, strong mechanical resistance
4) Anti-ageing EVA and excellent anti-climate back sheet
5) Anodized aluminum frame improves load resistance capabilities for heavy wind loads.
6) Standard waterproof junction box
7) High endurance to different weather
8) Good and friendly package with less transportation and storage space.
Warranty :
1)10 years limited manufacturing warranty
2)12 years for 90% of warranted minimum power
3)25 years for 80% of warranted minimum power
