Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > KDE3500X 3/3.5KVA Open Frame Single Cylinder Diesel Alternator Generator
KDE3500X 3/3.5KVA Open Frame Single Cylinder Diesel Alternator Generator
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
YASHIDA
Model Number:
KDE3500X
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KDE3500E 3/3.5KVA 3KVA Electric Small Portable Home Generator Open Diesel GeneratorNegotiableMOQ: 1 -
KDE3500T 3/3.5KVA Silent Portable Three Phase Diesel Generator Set for Home UseNegotiableMOQ: 1
-
KDE3500ST 3/3.5KVA Super Silent Small Air Cooled Portable Generator Silent Diesel GeneratorNegotiableMOQ: 1
-
KDE6500ST 5/5.5KVA Super Silent Portable Three Phase Diesel Generator Set for Home UseNegotiableMOQ: 1
-
KDE6500T 5/5.5KVA Silent Small Air Cooled Portable Generator Silent Diesel GeneratorNegotiableMOQ: 1
Place of Origin
Jiangsu, China
Brand Name
YASHIDA
Model Number
KDE3500X
Output Type
AC Three Phase
| Diesel generator set KDE3500X(E) | ||
| Model | KDE3500X(E) | |
| Rated Frequency (Hz) | 50/60 | |
| Rated power (KW) | 3.4/4 | |
| Rated Voltage (V) | 230/240 | |
| Rated Current (A) | 13.1 | |
| Rated Engine speed (r/min) | 3000/3600 | |
| DC Output | 12V/8.3A | |
| Phase | Single-phase | |
| Power factor(cosφ) | 1 | |
| Noise level (7m) | 72 | |
| Structure | Open-frame | |
| Coupled type | The Rotor Shaft Rigid Connection | |
| Engine Model | 178F(E) | |
| Engine type | Single-cylinder,4 Stroke,Vertical, Air cooled,Direct injection | |
| Compression ratio | 20:01 | |
| Engine starting system | Recoil or Electric | |
| Fuel model | Summer: 0#, winter: -10#, Chilliness:-35 | |
| Lube oil model | SAE10W-30 (above CC grade) | |
| Net weight (KG) | 64 | |
| Dimension(L*W*H) | 680×530×590 | |
