Help CenterMono 226W Solar Panel
US$ 0.48 - 0.58
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Risun
Model Number:
RSM60-156M/226W
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
A.High Efficiency 250W Mono Solar Panel With TUV,CE,CECUS$ 0.48 - 0.61MOQ: 1 Piece -
Top Quality Comoetitive Price 305w Poly Solar PanelUS$ 0.48 - 0.58MOQ: 1 Piece
-
A.Hot Sale Solar Panel 240W Poly Solar Panel With Good PriceUS$ 0.48 - 0.58MOQ: 1 Piece
-
A.Best Quality 250W Mono Solar Panel With TUV,CE,CECUS$ 0.48 - 0.61MOQ: 1 Piece
-
High Efficient 250W Mono Solar Panel With Good Quality, Low Price and TUV IEC CE CEC ISO INMETRO CertificatesUS$ 0.3 - 0.5MOQ: 1 Piece
Place of Origin
Jiangsu, China
Brand Name
Risun
Model Number
RSM60-156M/226W
Material
Monocrystalline Silicon
Size
1650*990*40
Number of Cells
60
Max. Power
226
Specifications
226W Mono Solar Panel Specifications1) high efficency
2) easy to install
3) stand heavy rain and snow
4) lower price
226W mono solar panel, solar module, solar panel specification:
| ITEM | 226W Mono Solar Panel |
||
| Maximum power (Wp) | 226 W |
230 W |
240 W |
| Maximum power voltage (V) | 36.42 |
36.93 |
37.49 |
| Maximum power current (A) | 8.35 |
8.44 |
8.54 |
| Open circuit voltage (V) | 29.76 |
30.16 |
30.56 |
| Short circuit current (A) | 7.39 |
7.63 |
7.86 |
| Number of cells (Pcs) | 60pcs(6x10) |
||
| Size of module (mm) | 1650*990*40 |
||
| Size of solar cells(mm) | 156x156 mm |
||
| Brand Name of Solar Cells | JingAo, CEEG,SOLAR FUN |
||
| Maximum system voltage (V) | 1000 |
||
| Temperature coefficients of Isc (%) | +0.04/°C |
||
| Temperature coefficients of Voc (%) | -0.38/°C |
||
| Temperature coefficients of Pm (%) | -0.4/°C |
||
| Temperature coefficients of Im (%) | +0.04%/°C |
||
| Temperature coefficients of Vm (%) | -0.38%/°C |
||
| Temperature Range | - 40°C~+85°C |
||
| Surface Maximum Load Capacity | 2400Pa |
||
| Allowable Hail Load | 23m/s, 7.53g |
||
| Weight per piece (kg) | 19 |
||
| Junction Box Type | With TUV certificate |
||
| Length of Cables (mm) | 900 |
||
| Cell Efficiency (%) | >15.00% |
>15.75% |
>16.45% |
| Module Efficiency (%) | >13.50% |
>14.13% |
>14.80% |
| Output tolerance (%) | ± 3% |
||
| Frame (Material, Corners, etc.) | Anodized Aluminum Alloy Frame |
||
| Standard Test Conditions | AM 1.5,1000W/m2, 25°C |
||
| Warranty | 25 years , 80% for 25 years |
||
working conditions:
| Maximum System Voltage | DC1000V(IEC) |
| Operating Temperature | -40°C~+85°C |
| Storage Temperature | -40°C~+85°C |
| Max. Wind Load / Max. Snow Load | 2400Pa/5400Pa |
| Application Class | Class A |
Any question please ask me feel free, and please add me Skype:.0724
