Specifications
190w poly solar module-5 years material and workmanship warranty
-big production capacity , produce according to client reque
risun hot good price 190w solar module
Specifications
180w solar module
5 years material and workmanship warranty.
big production capacity , produce according to client request
190w solar module Electrical Specifications
Model RSM170P-48 RSM180P-48 RSM190P-48
Max. power PMAX(Wp) 170 180 190
Max. power voltage UMPP(V) 23.5 24.4 25.0
Max. power current IMPP(A) 7.2 7.4 7.6
Ope ncircuit voltage Voc(V) 29.0 29.1 30.0
Short circuit current Isc(A) 8.0 8.16 8.4
Power Tolerance (%) ±5
Max. system voltage DC 1000V
Max.series Fuse 15 A
No.of Bypass Diodes 4 PCS
Mechanical Characteristics Frame Aluminium anodized,color: silver, black
Dimensions 1318×994×35mm
Weight 15 kg
Front Cover 3.2 mm ultra clear,low iron temperedglass, with high light transmittance.3.2mm,
Backside Cover TPT
Cells per Module 48 pcs (6X8)
Cell Type Polycrystalline 156*156mm
Temperature Coefficients
Norminal Operating Cell Temp.(NOCT) 47°C(±2%)
Temp. Coefficient Voltage (Voc) -0.32%/°C
Temp. Coefficient Current(Isc) +0.03%/°C
Temp. Coefficient Power(Pm) -0.42%/
Output(Optional) Warranty
Cable 2 * 900mm, LAPP 4mm2
Connector MC4 Compatible
Warranty
12 years warranty on 90% of nominal power output.
25 years warranty on 80% of nominal power output.
5 years material and workmanship warranty.
