cnc stone letter carving machine with heavy body
USD $1,000 - $10,000
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- Qingdao
- T/T L/C Credit Card
You May Like
- Granite Marble CNC Milling and Cutting Bridge Saw Machine Infrared Quartz 5 Axis Granite Tile Back Splash Machine Cnc
- Bridge saw type cnc stone cutting machine for marble granite quartz kitchen countertop
- automatic stone cutting machine/cnc granite cutting machinery Bridge Saw for stone countertop
- 2024 new CNC four-axis bridge stone cutting machine for Artificial granite marble slabs
- 5 axis 45 degree chamfering granite quartz bridge saw stone carving cutting machine
- Integrated Mobile Bridge Saw Adopts Microcomputer Control Used Marble Simple Stone Granite Infrared 5 Axis Cnc Cutting Machine
Product Details
Condition: | New | Type: | Stone Engraving Machine | Use: | Concrete Curb |
Production Capacity: | High | Place of Origin: | Shandong, China | Brand Name: | Multitech |
Model Number: | 1325 | Voltage: | 220/380V | Power(W): | 5.5KW |
Dimension(L*W*H): | 1300*2500*300mm | Weight: | 1500kg | Certification: | CE ISO |
Warranty: | 1 Year | After-sales Service Provided: | Overseas service center available |
Product Description
cnc stone letter carving machine with heavy body
Cnc stone letter carving machine advantage:
1)Stable bed structure: learning from Italian stone processing center models advantages of using direct connect gantry and bed design are supported to ensure the stable operation of the machine.
2) Ultra-high processing height: standard models feed height 300cm, customize can be up to 800cm, to meet the needs of a variety of sizes carving stone.
3) Overall stainless steel sheet metal: stone carving machine body all used stainless steel design, long running water environment does not rust corrosion, increasing the life of the bed
4) Reducer: Use Taiwan imported reducer drive, intensity, high precision, long life, good position, do not lose steps.
5)Japan Yaskawa servo motors: using high-power servo motor and drives, with self-feedback signal function is not lost during the operation step.
6) Running speed very fast, high efficiency, air-way speed up to 38 m / min, the working speed up to 9 m / min.
Parameter of stone letter carving machine:
Description | Parameter |
X,Y Working Area | 1300*2500mm |
Z Working Area | 300mm |
Resolution | 0.01mm |
Lathe Structure | whole cast iron |
X,Y Structure | Rack and pinion transmission |
Z Structure | Ball screw driving, |
Guide way | Linear Square rail |
Max. Idling Speed | 35m/min |
Spindle | 5.5kw water cooling spindle |
Spindle Rotate Speed | 0-24000r/min, variable speed |
Inverter | Delta inverter. |
Working Voltage | AC380V/50Hz |
Working Mode | Yaskawa servo motor and drivers |
Command | G code,HPGL,U00,mmg,plt |
Operating System | NC studio controller |
Diameter of cutter | φ3.175-φ12.7mm |
Cooling Mode | Water-cooling |
Work-holding | By suction or Clamp |
Certification | CE |
Samples of stone letter carving machine:
If you have any questions ,please contact with me !
Contact Us
- Jinan Itech Machinery Co., Ltd.
- Contact nameJoanna Qiao
- Phone86-0531-66593902
- AddressNo. 010-1, Qiaobei Ind. Zone, Daqiao Town, Tianqiao Dist.
