YAG laser marking machine for metal mugs pens clocks
Configuration :
YAG laser marking machine .This machine include:
#YAG Laser 50w from UK (It can marking on the carbon steel ,stainless steel ,all metal and most of non-metal )
#Laser Diode module 50W(75W is optional )
#Working area :100*100mm
#Table: Aluminum alloy and electric up-down table
#Water chiller (it can cooling the laser )
#PC control system (easy to learn )
#Q switch
#Scanning head
#EZCAD software (original with best quality )
#Singapore Lenses and mirror (Best quality and long lifetime)
#Graphic format: BMP,JPG,GIF,PNG,AI,DXF,DST,PLT,etc
#Support interface: all-English language ,Chinese,Japanese and Korean
#Material: mainly for All metal and most of non-metal material
#warranty is one year.if machine has any question,we can send you new parts for free
Feathers :
1. Adopts RF metal laser tube, imported from USA, characterized by excellent performance and long life time <20k hours>.
2. Full sealed and maintenance-free laser optic system which key components all imported from USA or UK, which install-and-play without adjustment.
3. Can quickly mark letter,figure,graphics or auto-coding ,serial No., batch No.,barcode,2 -D code, etc. nonmetal surface(plastic, silicon or porcelain, etc.) which are precise, permanent., non-polluting and environment-friendly.
4. Be applicable to production line for flying marking.
5. Rotary worktable system is optional, thus, accomplish marking on cambered surface.
6. With mirror marking function.
7. Under WINDOWS interface, compatible with files outputted from software such as CORELDRAW, AUTOCAD, PHOTOSHOP etc. Support PLT, AI, DXF, BMP and other documents, directly using SHX, TTF font.
Applicable :
1. mechanical industry: hardware, faucets, clutch, bearings, piston rings, steel pipe, steel, gears, shafts, etc.
2.electronic components: such as capacitors, inductors, circuit boards, integrated circuits, keyboards, etc.
3. instrumentation: the control panel, hardware tools, measuring tools, medical equipment, aviation parts and components
4.household appliances, packaging, stationery, designer panels, labels, signs, cosmetics, food, color paper, various paint products, tobacco, handicrafts, etc.
5.gold, jewelry and crafts, building materials, sanitary ware and so on.
Samples :
Technoloty Parameter :
Input voltage: |
AC220V±20V |
Frequency: |
50Hz |
Input power: |
1.5kw |
Wavelength: |
1.064µm |
Power: |
50W |
Instability: |
±5% |
Radio-frequency power: |
≤50W |
Modulating frequency power: |
200Hz~50kHz |
Pulse duration modulation: |
4µs~25µs |
Working area: |
110mmx110mm |
Scanning speed |
0~7000mm/s |
Marking depth: |
0.01~0.2mm (according to material) |
Marking width: |
0.1-0.2mm (according to material) |
XY table working area: |
85mm x 85mm |
Laser head lifting height: |
200mm |
Cooling way: |
Refrigeration unit cools the circulating media then the circulating media cools the laser cavity. |
Refrigerating power: |
1P |
Refrigeration unit: |
De-ionized water, distilled water or purified water. |
