Help CenterParking Lot Light With Motion Sensor Head,12W 198-242V AC
Related Products
-
LED Motion Activated Sensor Flood Lights,infrared Motion Detector Activated Light 4w, CE/ROHSUS$ 15 - 34MOQ: 10 Pieces -
LED Motion Sensor Flood Lights,infrared Motion Detector Activated Light 8w, CE/ROHSUS$ 15 - 35MOQ: 10 Pieces
-
LED Motion Sensor Flood Lights,infrared Motion Detector Activated Light 8w, CE/ROHSUS$ 15 - 35MOQ: 10 Pieces
-
Mini Infrared Motion Sensor Light DIP LED 4W 198-242V AC CE/ROHS,OUTDOOR IP 65US$ 15 - 45MOQ: 100 Pieces
-
Infrared,motion Sensor Light,SDM LED 12W,198-242V AC,CE/ROHS,OUTDOOR IP65US$ 15 - 45MOQ: 10 Pieces
led parking lot/areas motion sensor light
Led parking areas sensor light | |||
Item |
Parameters |
||
Power |
12W |
||
LED Quantity |
12PCS Bridgelux Hi Power SMD LED |
||
Color |
warm white/ neutral white / cool white |
||
CCT |
2700-3500K/4000-4500K/6000-7000K |
||
CRI |
≥80% |
||
Lifespan |
≥50,000 Hours |
||
Flux |
850lm |
||
Beam Angle |
15°30°45°60°75°90°120° |
||
Material |
Aluminum |
||
| Detection Range(Sensor Head) | 12m, 180° | ||
| Time Adjustment(Sensor Head) | 20S-10Min | ||
Net Weight |
MAX 1.25KG/PCS |
||
Gross Weight |
MAX 1.5KG/package |
||
Package Dimension(FCL) |
575*440*445mm |
||
Package Spec. |
12PCS/ CTN |
||
|
Technical Requirements | |||
Items |
Units |
Parameter Range |
|
Working Temperature |
°C |
-370C - 550C |
|
Working Humidity |
|
≤95% |
|
Storage Condition |
°C |
-40°C~80°C |
|
Rated Voltage |
V |
AC 198-242V, 50/60Hz |
|
Input Current |
A |
0.61-0.5 |
|
Protection Level |
IP54 outdoor |
||
Product features
1. As solid state lighting, switching frequency has nothing to do with the led lifespan, without flick or delay, no warm up time; these
features make motion sensor performance well than used to be.
2.Excellent light quality, no glare light emitting
3. Aluminum housing, resistant to damage and excellent heat dissipation, and recyclable.
4. Wide Voltage range, can work under low voltage, the brightness will not change with voltage fluctuation.
5. Great color rendering, color presentation is more realistic, more vivid, better light definition.
6. Long lifetime, lifespan is more than 50,000 hours. Less maintenance.
7. Eco-friendly, No pollution of Lead and Mercury, Lower energy
consumption and pollutants eliminated. will not attract insects,fly.
8. High luminous efficiency, save 70% electricity bill compared to traditional light.
Instruction of the sensor
1 can identify day and night light. Consumer can adjust the sensor according to work ambient. “SUN” position (max). “MOON” position (min) night light less than 3LUX.
2 Sensitivity adjustable: adjustable according to using location.5m (min) 12m (max).
3 Time delay is added continually, when it receives the induction signals successive, it will compute time once more on the rest of the first time delay base.
4.Time delay adjustment; It can be set depend on requirement.10sec±3sec(min) 7min±2min(max).
Application
Parking areas ,underground parking lot light.
