9w 24w Led Panel Light With CE RoHS UL Listed

9w 24w Led Panel Light With CE RoHS UL Listed thumbnail-1
9w 24w Led Panel Light With CE RoHS UL Listed photo-1
US$ 9 - 14 MOQ: 1 Piece
Key Specifications
Get Latest Price
LED Light Source:
Epistar
Warranty(Years):
3
Input Voltage(V):
100-277
Contact Supplier Request Quote Chat Now
SLT Lighting Technology (Dongguan) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source Epistar
Warranty(Years) 3
Input Voltage(V) 100-277
Lamp Power(W) 9
Lamp Luminous Flux(lm) 675
Lamp Luminous Efficiency(lm/w) 75
Color Temperature(CCT) Cool White
Working Temperature(℃) -20, 55
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum
IP Rating IP44
Certification BV, CCC, CE, CQC, EMC, FCC, LVD, UL
Place of Origin Guangdong, China
Brand Name SLTMAKS
Model Number STN-009DW2

You are here Home > Product Categories > LED Panel Light

  factory good quality high lumen led panel light, 60cmx60cm led panel light



Product Description

 Technical Parameters for LED Panel Light



Point Light Source Parameters: 9W LED flat panel light dimmable



Items
Parameter

Power

9W

LED

2835

Color

warm white/ neutral white / cool white

CCT

2800-3500K/4000-5000K/6000-7000K

CRI

≥85

Lifespan

≥50,000 Hours

Flux

840LM +/-50LM(Dimmer)

Beam Angle

120°

Material

Aluminum+Milky PC

Net Weight

MAX 1.06KG/PC



Gross Weight

MAX 12.5KG/CTN

Package Dimension

660*390*180mm

1





Technical Requirements



Items

Units

Parameter Range

Working Temperature

°C

-370C - 550C

Working Humidity



≤95%

Storage Condition

°C

-40°C~80°C

Rated Voltage

V

AC 90-264V, 50/60Hz

Input Current

 A

0.5-0.17

Protection Level

IP43



Features



 Dimmable

1.Can replace traditional LED tube lights, no need for ballast and starter, reducing the rate of failure;



2. Turn on the light immediately, no flicker and no delay, no  high-frequency noise;



3. Aluminum housing, resistant to damage and excellent heat dissipation, and recyclable;



4. Wide Voltage range, can work under low voltage, the brightness will not change with voltage fluctuation;



5. Great color rendering, color presentation is more realistic, more vivid, better light definition;



6. Long lifetime, lifespan is more than 50,000 hours;



7. Eco-friendly, No pollution of Lead and Mercury, Lower energy consumption and pollutants eliminated;



8.High luminous efficiency, save 60% electricity bill compared to traditional tube light.





Applications





They are designed for office buildings, factories, shopping malls, home indoor lighting and so on.





Attentions





1.Please use the correct power supply.



2.Please read the product installation manual carefully before using the products.
Features

Product Details for LED Panel Light

9w 24w led panel light with CE RoHS UL listed

Features for LED Panel Light

  • High efficiency & energy saving. Under the condition of the same illumination, the LED Panel Light can save energy up to 67%.
  • Long life span, using semiconductor chip as the light resource, the life time can be over 50,000hrs.
  • Special view angles, mixing lighting design.
  • No RF interference.
  • Eco-friendly. No Hg & Xe, or other harmful elements.
  • No flocker, no glare, the LED Panel Light is with very soft and even light.
  • Special circuit design, each LED can work seperately, thus it can avoid the influence that a broken LED causes.

Installation for LED Panel Light



Applications

Applications for LED Panel Light

LED Panel Lights are designed for homes, offices, hotels, shopping malls, supermarkets, cabinets and other ceiling lighting places.

9w 24w led panel light with CE RoHS UL listed

Packaging & Shipping

Packaging and shipping for LED Panel Light

  • Inner box: Every LED Panel Light will be packed with thick foam and special PE bag.
  • Outer package: Every inner box will be packed with thick and solid carton, whiich promise you get the perfect LED Panel Light after long term transportation.
  • Shipping: Every LED Panel Light will be sent to you of highest quality we can provide. Before shipping LED Panel Light to you , it must go through aging test, and get our strict QC manager's permission.
  • Freight: You are lucky to get the lowest freight for we have good long-term relationship with express companies.

9w 24w led panel light with CE RoHS UL listed

More Choices

Product Code Wattage Lumen Efficiency CRI Size LED DC Lumen
EPL3030-9w-75lm 9w >75lm/w >70

300*300mm

 2835 36V 225MA 630-670lLM
EPL3060-18w-75lm 18w >75lm/w >70 300*600mm 2835 36V 450MA 1200-1400LM
EPL6060-36w-75lm 36w >75lm/w >70 600*600mm 2835 36V 900MA 2400-2800LM
EPL30120-36w-75lm 36w >75lm/w >70 1200*300mm 2835 36V 900MA 2400-2800LM
EPL60120-60w-75lm 60w >75lm/w >70 1200*600mm 2835 36V 1500MA 4200-4500LM
EPL-3030-9w-85lm 9w >80lm/w >82 300*300mm 2835 36V 225MA 720-750LM
EPL-6060--40w-85lm 40w >80lm/w >82 600*600mm 2835 36V 1000MA 3200-3400LM
EPL-30120-40w-85lm 40w >80lm/w >82 1200*300mm 2835 36V 1000MA 3200-3500LM
EPL-60120-80w-85lm 80w >80lm/w >82 1200*600mm 2835 36V 1000MA 6400-6700LM
EPL-3030-9w-90lm 9w >90lm/w >82 300*300mm 2835 36V 225MA 810-850LM
EPL-6060-40w-90lm 40w >90lm/w >82 600*600mm 2835 36V 1000MA 3600-3800LM
EPL-30120-40w-90lm 40w >90lm/w >82 1200*300mm 2835 36V 1000MA 3600-3800LM
EPL-60120-80W-90lm 80 >90lm/w >82 1200*600mm 2835 36V 1000MA 7200-7500LM

9w 24w led panel light with CE RoHS UL listed

Our Services

Services

  1. We can provide high quality led lights.
  2. We make sure to give the most competitive prives to you.
  3. We provide 3 years warranty. During this period, you can enjoy free replacement once the led lights fail under proper operation.
  4. We have long-term cooperation with our forwarders, so we can get the lowest freight and the fastest shipping services for you.
  5. We can do OEM/ODM.
  6. Quickly response on your inquiry.

Warranty

  1. The warranty period starts on the date of purchase invoice.
  2. You will get free repair and replacement once the led lights fail under proper operation during warranty period.
  3. You can not get free repair and replacement for improper operation.
  4. Do not attempt to open the light and repair as this could invailidated warranty.

9w 24w led panel light with CE RoHS UL listed
