64GB/128GB/256GB Sd Card 4ch mobile dvr distributor

Name: 64GB/128GB/256GB Sd Card 4ch mobile dvr distributor
Brand: VisionMaster/OEM
Price: USD $59 - 235 / Set

FOB Price

USD $59 - $235 / Set

1 Set(Min.Order)

Supply Ability 5000 Set / Sets per Month
Port FOB Shenzhen
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Guangdong, China

Brand Name:

VisionMaster/OEM

Model Number:

VM-1504-HD

Product Description

64GB/128GB/256GB Sd Card 4ch mobile dvr distributor

Advantages

VISIONMASTER PRODUCTS' Advantages :

1. Power failure protection.

2. Wide voltage (6-48V, Seldom other companies can achieve this function, other companies only can achieve 8-36V).
3. OTA function support. (Upgrating DVR software automatically, better after-sales service for you.
4. A SMS can get DVR situation feedback from DVR

5. Industrial level design. (More professional and better quality.)
6. Modular design. (To prevent a module error while affecting the entire product.)
7. Encrypt video format. (To prevent data loss)
8. Current and voltage over protection.
9. Wide working temperature. (-25°C- +75°C).
10. Data redundancy technology. (To prevent data loss)
11. Excellent vibration protection.

Highlights for VM-1504-HD Series:

1. Cost effective: With low price to enjoy hig definition experience;

2. Compatibility: Compatible with both common analogue cameras and analogue high definition cameras;

3. Compact Size: 112(W) x36(H) x138(D) mm, Weight: 360g

4. Dual SD cards supported: Maximum supports two SD cards 128GB each.

Product Description

Parameters:

Item	Parameter
Model	VM-1504-HD
Os	Linux
Language	chinese/English/Customized
Video compression	H.264
GUI	Setup system parameters with the remote control
Video record system	video input	4CH 720P AHD input,aviation connector
	video output	1 CVBS,Aviation,Support 1CH Full Screen,4CH Screen
	preview	Support 1 channel and 4 channels preview.Support Manual/Alarm Trigger fullscreen preview
	resolution	720P/D1/HD1/CIF MAX:4 channels of 720P and 4 channels of D1
	video quality	1-4 levels ,1 is the highest level
	viedo standard	P/N/CIF/HD1/D1/720P
	record mode	auto recording after power on/ Timed recording/alarm trigger recording/ manual recording
Audio	audio input	4ch aviation plug
Audio	audio output	1ch aviation plug
Alarm	alarm input	4ch Alarm Input, kinds of alarm linkage support
Alarm	alarm output	1ch Alarm Output
Multi-funtion	Gps /3G/4G/WIFI/G-sensor
Storge capacity	dual SD Card,each max 128GB SD Card loop recording
Video palyback	Max support 4CH Replay /Stop/Fast/Slow at same time
Video palyback	support forward and backward play at the speed of: x 2,x4,x8,x16
Voltage & Power	voltage Input	DC:+10V ~ +36V
	voltage output	+12V/2.5A; +5V/2.5A
	power consumption	Normal working < 5w
Working Environment	temperature:-20℃ to +70℃////humidity:20% to 80%
Security	User/Admin 2 Level Different Password
Size/ Net Weight	112(W) x36(H) x138(D) mm////360g

Detailed Images

NEW PRODUCT 720P AHD ( ANALOG HD DEFINITION ) MOBILE DVR

Free PC CMSV6 Remote Client software:

Free Phone CMSV6 Remote Client software:

Application

Widely used in passenger car,bus,taxi,school bus,lorry,dangerous vehicle, personal car and ship etc.

Packaging & Shipping

VM-1504GWT-HD Standard Packing List:

Neutral Package:

We support various mode of transportation for shipment :

By sea:15~40 days arrive

By air :2~5 days arrive

By express:-~7 days arrive

By air -mail :15~70 days arrive

More Products for you to Choose:

Company Information

Visionmaster Industrial Co., Ltd. is a leading video surveillance solution provider with global perspective. Before we got this new company name(Visionmaster), we have been in the field for 8years. Our team has been steadily growing from the initial 3 founders up to more than 100 employees. Through our dedication to customer-centric innovation and strong partnerships, we are creating maximum value for international distributors, installers by committing end user competitive mobile surveillance and DVR solutions. Our solutions have been deployed worldwide among various applications including public transportation, school bus, law enforcement, private fleet, logistics management, railway and metro, mobile media operation, etc. We continue to enjoy rapid and steady growth and would like to invite you to be part of our global success. Please do not hesitate to pick up the phone or send us an email to find out how.

FAQ

Q:When Device issue appear,you are confused on how to solve it.
A:Check Device Item No & Firmware Version,sent back to us with detail description of issue.Our

Technical Team will handle it.More detail you described,easier for us to solve it quickly

Q: When SD card and HDD records, How is the record coverage?
A: SD card and HDD will record circularly for each other. When they are full, they will delete the

original video records respectively.

Q: Can’t playback files on PC successfully?
A: Possible reason is as follows:

1.Have never chosen a record file or document path; please choose the path that records file first

before playback.
