Burger Forming Machine

Specifications

Burger forming machine
Various size and shape
Fully stainless steel 304
Make hamburger patty, nugget, beef steak, hash brown

 Instruction

APF Series burger forming machine is suitable to make hamburger patty, chicken nugget, beef steak, fish cake, hash brown potato, etc. The shape and sizes can be various by changing different moulds.

Sample picture

Features

APF Series Hamburger Patty Former can automatically perform all procedures including material filling, forming and output. It features high production capacity and stable quality. The material feeding is by four-screw system, which can greatly reduce the cutting of the material, and has better features of high production capacity and stable quality.

The raw materials can widely be any meat, fish, shrimp, potato, pumpkin, carrot, green beans, vegetable, and tubers. APF Series Hamburger Patty Former can also be applied in fields of all kinds of minced / sliced products for premier meat texture taste. Easy and convenient raw material replacement and accurate weight control make it possible to control the production cost.

The machine is more safe and reliable by using good quality stainless steel nonmetal materials. This conforms to the standards of HACCP. Using original Germany SIEMENS PLC processor, allocating auto failure alarm system and touch screen in bilingual languages make it safe and convenient for operation.

Technical parameter

Model	APF-200	APF-400	APF-600
Power	0.55kw	12kw	15kw
Max. output	50-100kg/hr	500-600kg/hr	1000-1200kg/hr
Speed	15-30times/min	15-55times/min	15-60times/min
Patty thickness	6-20mm	6-30mm	6-40mm
Max. patty diameter	100mm	135mm	150mm
Patty weight error	≤1%	≤1%	≤1%
Tank Volume	32L	150L	200L
Raw material type	Versatile	Versatile	Versatile
Filling pressure	Mechanical type	3-15Mpa	3-15Mpa
Weight	90kg	1100kg	1500kg
Dimension (L x W x H)	715 x 600 x 1400mm	2828 x 830 x 2136mm	3170 x 1180 x 2640mm



1. We make accurate factory layout design according to customer’s factory size; if the customer needed, we could make workshop design with electricity power, water supply, gas power, material storage, final storages, worker’s restroom, etc.

2. After delivering machines to client’s factory, we start to apply for the Visa to client’s country immediately; normally the vessel needs 20-60 days to the required port, so we have enough time to get the Visa. While the machines arrives your factory, our engineers are ready to start for the commissioning service.

3. 1-2 of our engineers will go to your factory to install and adjust the processing line to realize normal production at shortest time.

4. Our engineers have responsibility to train and teach the workers how to operate, clean, maintain and repair all the machines, until the workers could well operate the processing line.

5. It normally costs 10 days for the commissioning service, and we supply 1 year guarantee from the date of completion of commissioning service.

6. The engineer’s round-trip flight tickets, accommodation and daily salary USD 60 are on client’s account.
