Metal Case CE RoHs IP67 Dc12v 60W 5A Outdoor Power Supply
- Ningbo or Shanghai
- T/T L/C D/P D/A Credit Card
You May Like
-
IP67 For Outdoor LED Lighting LDV-60-5 Over Load Protection 60W Led Driver Waterproof
-
Waterproof 12V 2.5A 30W Constant Voltage Led Driver IP67 High Quality LDV-30 Power Supply Used for Outdoor
-
Constant Voltage LDV-200-12 Waterproof IP67 Design 200w 12v LED Driver
-
Constant Voltage LDV-200-36 IP67 Design 200w 36v Waterproof LED Driver With 2 Years Warranty
-
IP67 CE RoHS High Efficiency Led Driver 12V
-
IP67 CE RoHS 18W Single Output 36V Waterproof Led Transformer
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Leyu outdoor power supply | |
| Model Number | LDV-60-12 | Output Power | 101 - 200W | |
| Output Type | Single | Input Voltage | Other, 180~264VAC | |
| Output Voltage | 24V outdoor power supply | Output Frequency | 50/60hz | |
| Output Current | 5A |
Product Description
Specifications
outdoor power supplyA.Passed ip67 waterproof dustproof grade test
B. LED street lighting outdoor LED lighting application
Metal case CE RoHs IP67 dc12v 60W 5A outdoor power supply
60W Single Output Waterproof Switching Power Supply LDV-60 series
SPECIFICATION | ||
OUTPUT |
| |
Model | LDV-60-12 | LDV-60-24 |
DC Voltage | 12V | 24V |
Rated Current | 5A | 2.5A |
Current Range | 0-5A | 0-2.5A |
Rated Power | 60W | 60W |
Ripple & Noise | 120mVp-p | 120mVp-p |
Voltage Adj. Range | ±10% | ±10% |
Voltage Tolerance | ±1% | ±1% |
Inlet Stability | ±0.5% | ±0.5% |
Load Stability | ±0.5% | ±0.5% |
Setup, Rise, Hold Up Time | 800s,50ms,10ms/115VAC 300ms,50ms,80ms/230VAC | |
|
| |
INPUT |
| |
Voltage Range | 170~250VAC 50-60Hz | |
AC Current | 2A/115V 1A/230V | |
Efficiency | 76% | 79% |
Inrush Current | Cold-start current 30A/115V 60A/230V | |
|
| |
PROTECTION |
| |
Over Load | 105%~150% | |
plusing hiccup shutdown Reset:auto recovery | ||
|
| |
ENVIRONMENT |
| |
Working Temp., Humidity | -10℃~+60℃(Refer to output derating curve),20%~90%RH | |
Storage Temp., Humidity | -20℃~+85℃, 10%~95%RH | |
Temp. Coefficient | ±0.03%/℃(0-50℃) | |
Vibration | 10-500Hz,2G 10min,/1cycle,Period for 60min,Each axes | |
|
| |
SAFETY |
| |
Withstand Voltage | I/P-O/P: 3KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC | |
Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC | |
|
| |
STANDARD |
| |
Safety Standard | UL1012TUV EN60950(IEC950,UL1950) Approved IP67 | |
EMC Standard | CLSPR22(EN55022),IEC801-2,3,4,IEC555-2 Verification | |
|
| |
OTHERS |
| |
Dimension | 190*49*35mm(L*W*H) | |
Weight | 0.5Kg | |
