Ups Charging Power Supply 35w 12v High Quality Low Price Power Supply Hot Sale in South Africa for Power Failure

Ups Charging Power Supply 35w 12v High Quality Low Price Power Supply Hot Sale in South Africa for Power Failure photo-1
Ups Charging Power Supply 35w 12v High Quality Low Price Power Supply Hot Sale in South Africa for Power Failure photo-2
Ups Charging Power Supply 35w 12v High Quality Low Price Power Supply Hot Sale in South Africa for Power Failure photo-3
Ups Charging Power Supply 35w 12v High Quality Low Price Power Supply Hot Sale in South Africa for Power Failure photo-4
Ups Charging Power Supply 35w 12v High Quality Low Price Power Supply Hot Sale in South Africa for Power Failure photo-5
US$ 9.02 - 9.92 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
LEYU
Model Number:
SCP-35-12
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo or shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name LEYU
Model Number SCP-35-12
Output Power 1 - 50W
Output Type Single
Input Voltage Other, 85~264VAC 120-370VDC
Output Voltage 13.8V SCP-35-12
Output Frequency 50/60Hz
Output Current 2.6A SCP-35-12





35W Single Output UPS function Power Supply         SCP-35 series

  ups charging power supply 35w 12v high quality low price power supply hot sale in South Africa for power failure

Features:

1. Universal AC input/Full rang

2. Protection: Short circuit / Overload / Over voltage / battery polarity protections(by fuse)

3. Cooling by free air convection

4. LED indicator for power on

5. No load power consumption<1W

6. Suitable for installation in metallic or non-metallic system enclosure

7. 100% full load burn-in test

8. 2 years warranty



SPECIFICATION

OUTPUT



Model

SCP-35-12

SCP-35-24

DC Voltage

13.8V

27.6V

Rated Current

2.6A

1.4A

Current Range

0-2.6A

0-1.4A

Rated Power

35.9W

38.6W

Ripple & Noise

120mVp-p

200mVp-p

Voltage Adj. Range

+15,-5%

+15,-5%

Voltage Tolerance

±2%

±1%

Inlet Stability

±1%

±1%

Load Stability

±2%

±1%

Setup, Rise, Hold Up Time

500ms,30ms/230VAC  1200ms,30ms/115VAC at full load





INPUT



Voltage Range

85~264VAC   120-370VDC

Frequency Range

47-63Hz

AC Current

0.7A/115V     0.5A/230VAC

Efficiency

83%

86%

Inrush Current

Cold-start 45A

Leakage Current

<2mA/240VAC





PROTECTION



Over Load

3.1A~4.2A rated output power

1.7A~2.3A rated output power

Protection type: hiccup mode,recovers automatically after fault condition is removed

Over Voltage

16.6~19.3V

33.1~38.5V

Protection type: shut down o/p voltage, re-power on to recover





ENVIRONMENT



Working Temp., Humidity

-20℃~+60℃(Refer to output derating curve),20%~90%RH

Storage Temp., Humidity

-40℃~+85℃, 10%~95%RH

Temp. Coefficient

±0.05%/℃(0~45℃)

Vibration

10~500Hz,2G 10min,/1cycle,Period for 60min,Each along X.Y.Z axes





SAFETY



Withstand Voltage

I/P-O/P: 3KVAC   I/P-FG: 1.5KVAC   O/P-FG: 0.5KVAC

Isolation Resistance

I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC





STANDARD



Safety Standard

UL60950-1,CCC,CE

EMC Standard

EN55022,CLASS B





OTHERS



Dimension

99*97*38mm(L*W*H)

Net weight

0.3436Kg

Weight

0.4Kg/pc  45pcs/carton

ups charging power supply 35w 12v high quality low price power supply hot sale in South Africa for power failure

 ups charging power supply 35w 12v high quality low price power supply hot sale in South Africa for power failureups charging power supply 35w 12v high quality low price power supply hot sale in South Africa for power failureups charging power supply 35w 12v high quality low price power supply hot sale in South Africa for power failure



Our Services

1.your inquiries will be replied within 24 hours;

2.OEM/OEM available:

a)Print logo on our products

b)Customized specification

c)Customized color package cases

d)Any require about our products, we will customized for you and put it into production in advance.

3.High quality, fashion design,reasonable&competitive price , fast delivery time.

4.After-selling service:

a)all products will adopt strictly testing (Burn-in test) before packing

b)All products will be packed before shipping

c)All products have 1-2 years warranty

5.Fast delivery:

Sample order in stock generally ,and 7-15 days for mass production

6.Payment term:

T/T , western union & paypal

7.Shipping

We have long-term cooperation with DHL,TNT,UPS,FEDEX,EMS,china post air mail, you also can choose your own shipping forwarder.

Welcome my dear friend ,looking forward to get your inquiry. All your inquiry will be replied within 24 hours. Please contact me!
