Insulating Glass Processing Machine Vertical Insulating Glass Production Line (Plate Press)
US$ 13,650 - 23,550
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
JINANYUEFENG
Model Number:
GPL-XY1600
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Tilting Table-window MachineUS$ 350 - 600MOQ: 1 Set -
Butyl Extruder MachineUS$ 4,500 - 7,000MOQ: 1 Set
-
Two-component Extruder-window MachineUS$ 5,500 - 9,000MOQ: 1 Set
-
Insulating Glass Processing MachineTilting TableUS$ 420 - 725MOQ: 1 Set
-
Insulating Glass Processing Machine Vertical Insulating Glass Production Line (Plate Press)US$ 16,900 - 29,190MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
JINANYUEFENG
Model Number
GPL-XY1600
Specifications
1.easy operation2.reliable performence
3.advenced technique
nvenient
Introduction:
- It is a completely automatic insulating glass production line (can produce LOW-E
insulating glass).
- Then entire machine adopts the PLC controls the working condition.
- Adopts the imported vacuum generator and sucker, the suction effect to the glass could
be much better.
- Bases the customers’ different request, the entire machine can be improved and
produce the Step IG Unit and three Piece IG production.
- Full distance automatic changeable frequency speed adjustment, which can save work
waiting time and improve production efficiency.
- When glass is pressed, the front and back part of flat pressing machine willup the glass
with lever- type arm and hand system,( machenical positon + mobile sucking system)
all this will ensure no malposition.
Technical Parameter:
Model |
GPL-XY1600 |
Input voltage |
380V 50Hz |
Input power |
13.5Kw |
Max. glass size |
1600×2350mm |
Min. glass size |
280×400mm |
Glass thickness |
3~10mm |
Working speed |
5~45m/min |
Overall dimension |
13500×1250×2600mm |
