Double Glazing Full Automatic CNC Insulating Glass process line
- 10 Set / Sets per Month
- QINGDAO
- T/T
Product Details
Condition: | New | Machine Type: | Insulating Glass Production Line | Place of Origin: | China |
Brand Name: | YueFeng Machine | Model Number: | GPL-XY2500 | Voltage: | 380V |
Power(W): | 26.5KW | Certification: | Other, CQC | Warranty: | One Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Three pairs brushes available for low-E glass.
1. PLC control two touch screen system, realize temperature, speed, output and machine
trouble prompting, realize whole line under automatic control.
2. Realize glass pressing automatically outside or inside the press machine, produce
insulating glass with two or three pieces original glass. It could produce insulating glass
come from glasses that is same size or different size.
3. Full distance five step frequency control speed changing, the waiting section of line save
time for whole process and improve working efficiency.
4. Action board can open, easy to examine and repair.
5. When glass is pressed, the front and back part of flat pressing machine will up the glass
with lever-type arm and hand system, (mechanical position + mobile sucking system) all
this will ensure no malposition.
6. Inside part of Wash machine, dry machine and the air dryer are both stainless steel
production. It is elegant appearance and never rust
Packaging Details: | wooden case or according to your request. |
---|---|
Delivery Detail: | within 30days since down payment opening date |
Model | GPL-XY1800B |
Input voltage | 380V 50Hz |
Input power | 23.5Kw |
Max. glass size | 1800×2500~2600mm |
Min. glass size | 280×400mm |
Glass thickness | 3~18mm |
Working speed | 8~45m/min |
Overall dimension | 19000×2350×2830mm |
Jinan Yuefeng Machinery Co., Ltd., founded in 1983, specializes in developing and manufacturing PVC window machines, aluminum window machines, curtain wall machines, and insulating glass machines. We are the foremost pioneer in the window & door industry.
Yuefeng has a fully equipped machining center and highly qualified technicians. Our years of experience and constant technical innovation have resulted in high quality machines. Our machines are capable of meeting a variety of production needs. Each project is handled uniquely and is customized according to each customer's individual situation. We work closely with each customer to find the best possible solution. Our customers are kept satisfied over the past 25 years.
Yuefeng aims to further enlarge our customer portfolio by using uncompromising quality in our products and by providing outstanding service around the world.
