Specifications
Rack-mounted Digital Video Optic Transceiver1, high quality
2, Good Price
3, 3 years warranty
4, CE FCC ROh
Rack-mounted Digital Video Optic Transceiver
Introduction
Rack-mounted chassis is a centralized and economical equipment of gather Ethernet media converter together. It covers two styles, 16 slots and 18 slots, mostly used in plant room with centralized dual power supply and automatic switch. Normal size are 2U and 4U, 2U is for 16 slots,
4U for 18 slots.
Features
* Main and vice power equipment ensure system work smoothly.
* Function cards supports hot-plugging and each card realizes its corresponding function independently.
* Double power panel slot supports two power supply units backup for each other.
* It would enhance the reliability of the rack.
* Supports 220V/110V AC switch mode power supply (SMPS) design.
* Power supply and other parameter state indicator LED can monitor the operation condition of system.
* Up to 16 or 18 available card type video converter module slots, 16 or 18 slots.
* With stable performance, large capacity of power supply, and easy for management and maintenance.
* All of the modules installed in the chassis are hot-swap, which makes it unnecessary to power-down the chassis when replacing modules.
* Support telecommunication operation requirement completely.
Technology Specification
Structure : 2U Rack
Ripple wave : ≤20mv
Power input : AC85~265V 50/60HZ or 48V
Power output : DC5V
Power adapter: single power supply or dual power supply
Power: 95W
Operating Temperature : -10~55℃
Operating Humidity : 5%~95%
Storage Temperature : -40~70℃
Storage Humidity : 5%~95% no condensing
Dimension: 490mm x 230mm x 90mm for 2U Rack
430mm x 260mm x 180mm for 4U Rack
Order Information:
Part Number |
Description |
BT-2U-D110/D220 |
16slot, 2U 19”, Dual power supply, AC110V/220V |
BT-2U-D48 |
16slot, 2U 19”, Dual power supply, DC48V |
BT-2U-S110/S220 |
16slot, 2U 19”, Single power supply, AC110V/220V |
BT-2U-S48 |
16slot, 2U 19”, Single power supply, DC48 |
BT-4U-D110/D220 |
18slot, 2U 19”, Dual power supply, AC110V/220V |
BT-4U-D48 |
18slot, 2U 19”, Dual power supply, DC48V+AC220V |
BT-4U-S110/S220 |
18slot, 2U 19”, Single power supply, AC110/220V |
BT-4U-S48 |
18slot, 2U 19”, Single power supply, DC48V |
|
2U 19”16 Slots Rack for Video Converter
|
4U 19”18 Slots Rack for Video Converter
|
|
4U 19”18 Slots Rack for Video Converter
|
4U 19”18 Slots Rack for Video Converter
|
Shenzhen B&TON Technology Co., Ltd is one of the powerful and high-tech companies specialized in researching, manufacturing and marketing of optical and fiber communication technologies. Our major products are media converter, digital video optical transmission systems and Optical Transceiver Modules.
2014 CIOE Exhibition in Shenzhen:
Workshop View:
Certificate:
Payment Method:
TT(Wire transfer), Western Union, Paypal.
Our advantages:
1 10 years experience for Fiber optic products manufacturing and exporting
2 Guaranteed Ordering finished in time
3 Quick Feedback
4 Delivery Date Guaranteed
5 High quanlity Guaranteed
6 Offer the whole technical support
7 Customization
8 Best aftersale service
9 CE FCC Rohs
10 Three years warranty
If trademanager is not online, Call me for the price! Or add online-service Skype #: Btonnet06.
