16 Port PoE Switch with 16 PoE Ports and 2 SC Fiber Port
Features
Can supply power to network surveillance cameras that without PoE function
9x 10/100Mbps auto-sensing RJ45 ports, 8x 10/100Mbps PoE ports, 1x 155Mbps SC fiber port
Supports port auto-flip (Auto MDI/ MDIX)
External power supply
Maximum PoE ports power: 120W (Port 1 to Port 8)
Maximum power of single PoE port: 15.4W
Adopts store-and-forward architecture
IEEE 802.3af power on up to 8 ports
Features with fanless, natural cooling, small, compact and quiet design, suitable for desktop or wall
Built-in 1U rack power supply series, easy to place it into standard mounting brackets
Specification
Product Name |
9-Port PoE Switch with 8 PoE Ports and 1 SC Fiber Port |
Product Model |
POE31008PF |
Connector |
9x 10/100M copper cable RJ45 ports(all ports support MDI/MDIX) 8x PoE ports, 1x 155Mbps SC fiber port |
Transfer Mode |
Store-And-Forward |
Network Medium |
10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or more UTP (≤100 meter) |
Data transmission distance: 100m; Fiber transmission: 25km | |
Performance Specifications |
Bandwidth: 1.6Gbps (non-blocking) |
Network Protocols and Standards |
IEEE 802.3i 10BASET |
LEDs Status |
System: power supply |
Power |
Maximum PoE power: 120W |
Dimensions/Weight |
Dimensions(LxWxH): 195x110x35mm, 0.52kg |
Working Environment |
Operating Temperature: 0 ° ~ 55 ° C Storage Temperature: -20 ° ~ 75 ° C Operating Humidity: 10% ~ 95%, non-condensing |
Radiation |
CE mark, commercial |
Safety |
CE Mark ,commercial |
Warranty |
1 year warranty(2 yeas warranty for power adapter) |
|
Product Dimension Display |
Product Application Diaplay
Product Application Display
Product Application Display
Factory Display
Products Display
Gigabit 8 Port POE
Gigabit 16 Port POE
100M 4 Port POE
