5-Port PoE Switch with 4 High Power PoE Ports and 1 SC Fiber Port
10/100M unmanaged PoE switch can provide both 10/100M Ethernet data and Power over network cable, it can be used as Ethernet Power Sourcing Equipment, it can automatically detect and identify whether connected devices such as IP camera comply with standard IEEE PoE 802.3af, 802.3at and supply power for them. 10/100M unmanaged PoE switch easier the deployment of Wilress AP, IP camera and IP-based network equipment. PoE Technology is Power over Ethernet technology, It is refering to transfer both Ethenet data and and DC Power at the same time for IP Phone, Wilress AP, IP-based camera. These devices which receive DC power is called Powered Device(PD)
1.IEEE 802.3af power on up to 4 ports
2.Supply power to wireless access points and surveillance cameras over Cat-5 cabling
3.5x 10/100 Mbps Ports with AutoUplink™
4.Supports PoE power up to 15.4W for each PoE port
5.Supports PoE power up to 65W for all PoE ports
6.Supports PoE IEEE 802.3af compliant PDs
7.Supports IEEE 802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
8.2K entry MAC address table of the PoE Switch with auto-learning and auto-aging
9.LED indicators for monitoring power, link, activity and speed
10.External power adapter supply
Shenzhen Bton Technology Co., Ltd is one of the powerful and high-tech companies specialized in researching, manufacturing and marketing of optical and fiber communication technologies. Our major products are media converter, digital video optical transmission systems and Optical Transceiver Modules.
Product: BT-P401E
Type: 5-PORT 10/100 switch with 4 PoE ports, IEEE 802.3af;
PoE Power Output: 15.4Watts per port. Total power consumption: 65Watts
Mid-span: Data provided over pairs over 1/2 and 3/6 ,Power over spare pairs4/5(+) and 7/8 (-)
End-span: Data and Power provided over 1/2(+), 3/6(-) , OPTIOANL
Package Contents |
5-Port 10/100 SWITCH with 4 POE ports and 1 Uplink (BT-P401E) |
AC Adapter | |
User Guide | |
Warranty Card |
