similar to Fujikura 70s Sumitomo type39 lowest price Fusion Splicing Kit Optical Fiber Splicing Machine
1.Core to Core Alignment (PAS)
2.8s splice time
3.256X magnification
4.Machine
Fiber Optic Splicing Machine
107 is a new designed fiber splicing equipment.The powerful funtcion and super low splicing loss make it be competent for construction of trunk line and FTTX :Because of the compact configuration and precise mechanism,it can adapt to execrable enviroment; The novel fiber imaging system make the image clearer and exquisiter;The real-time embeded OS provide friendly man-machine interface and abundant functions. The bulit-in large capacity Li-Ion battery can support long-time fieldwork.The embeded sensors measured temperature, humidity and air pressure supply closed-loop feedback control ,so the instrument can adopt all kinds of atrocious circumstance and the consistency of splicing loss was improved.
Fusion splicer is used for joining two optical fibers end-to-end using heat, to fuse the two fibers together in such a way that light passing through the fibers is not scattered or reflected back by the splice, and so that the splice and the region surrounding it are almost as strong as the virgin fiber itself. Skycom T-107H is multipurpose optical fiber splicing machine which is applicable for single fiber and rubber-insulated cable.
MainFeatures:
♦ 5 inches high Resolution colorful LCD display
♦ Average splice time: 10 seconds
♦ Average tube-heat time: 30 seconds
♦ Lithium battery: up to 180 times of continuous splice and heat
♦ Simultaneous X and Y views with 200 times magnification
♦ New developed technology providing wind and dust resistance
♦ Splicing mode: Auto & Manual
♦ USB Port
♦ Storing 6,000 groups of splice results
♦ Multipurpose optical fiber fixture (Such as: Rubber-insulated wire, fiber optic patch cord, bare fiber)
Specifications: |
|
| Applicable Fibers | SM, MM, NZ-DS, EDF , Pigtail, Rubber-insulated series wire Series |
| Average Splice Loss | 0.02dB(SM), 0.01dB(MM), 0.04dB(NZDS), 0.04dB(EDF) |
| Return Loss | ≥60dB |
| Tension Test | 2.0N(200gf)(Standard) |
| Typical splicing time | 10 seconds |
| Typical heating time | 30 seconds |
| Splicing Program | 50 groups |
| Protection Sleeve Length | 20mm, 40mm, 60mm |
| Operating Language | Chinese, English |
| Operating Conditions | -10~+50°C(operation temperature),0~95% RH(humidity), 0~5000m(altitude) |
| Power Supply | AC adaptor: 100~240V input voltage, 50/60Hz; 12V, 5A output voltage(DC) / 12V 8AH lithium battery |
| Monitor | 5 inches high Resolution colorful LCD display |
| Fiber image magnification | Simultaneous X and Y views with 200 times magnification |
| Storage of splice result | 6,000 groups of latest splice results |
| Splicing Model | Auto & Manual |
| Optical Fiber Fixture | Bare Fiber & Rubber-insulated Wire |
| Dimensions | 155(W)*165(D)*150(H) |
| Weight | 2.5kg |
107 Fiber Splicer+ AC power adopter+ Fiber Cleaver+ Li-Ion battery+ Standby electrode+ Blower brush+ Bottle with siphon+ Fiber bracket+ User’s manual+ Luxury tote kit
1. Item shipped in 3-15 working days after payment is received depends on the quantity of the order.
2. Item shipped by sea and air or UPS, FedEX, DHL and others, depending on size and weight of total order.
3. We accept T/T, L/C, Western Union, Money Gram and PayPal, just choose what you like
Shenzhen Bton Technology Co., Ltd is one of the powerful and high-tech companies specialized in researching, manufacturing and marketing of optical and fiber communication technologies. Our major products are media converter, digital video optical transmission systems and Optical Transceiver Modules.
If you have interest, Call me for the price! Or add online skype: amilybtonnet05
