Drilling Pipe E75 X95 G105 S135

Negotiable MOQ: 10 Tons (Price negotiable depending on order volume and customization)

Key Specifications

Standard:

Grade:

Thickness:

7.11, 12.7

Lijin Hongsheng Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao/tianjin

Delivery Detail:

Delivery time depends on order quantity.

Thickness 7.11, 12.7

Section Shape Round

Outer Diameter 60.3 - 139.7 mm

Place of Origin China

Secondary Or Not Non-secondary

Application Drill Pipe

Certification API

Special Pipe API Pipe

Specifications

1) OD: 2 7/8", 3 1/2", 4", 4 1/2", 5" 5-1/2"
2) Steel Grade: E75, X95, G105, S135
3) All drill pipe are made according to API

1) OD: 2 7/8", 3 1/2", 4", 4 1/2", 5" 5-1/2"

2) Steel Grade: E75, X95, G105, S135

3) Type of end finish: EU-external upset, IEU-internal & external upset

4) All drill pipe are made according to API 5D

5) We can provide in many conditions, with or without hard banding (Arnco100, Arnco300, tungsten carbide etc).

Size Designation		Nominal	Calculated Weight Wpe		Grade	Wall Thickness		Upset Ends, for Weld-on Tool Joins(see note)
in.	mm	Weight	lb/ft	kg/m	Grade	in.	mm	Upset Ends, for Weld-on Tool Joins(see note)
2 3/8	60.3	6.65	6.26	9.32	E,X,G,S	0.28	7.11	EU
2 7/8	73	10.4	9.72	14.48	E,X,G,S	0.362	9.19	EU IU
3 1/2	88.9	9.5	8.81	13.12	E	0.254	6.45	EU IU
3 1/2	88.9	13.3	12.31	18.34	E,X,G,S	0.368	9.35	EU IU
3 1/2	88.9	15.5	14.63	21.79	E	0.449	11.4	EU IU
3 1/2	88.9	15.5	14.63	21.79	X,G,S	0.449	11.4	EU IEU
4	101.6	14	12.93	19.26	E,X,G,S	0.33	8.38	EU IU
4 1/2	114.3	13.75	12.24	18.23	E	0.271	6.88	EU IU
4 1/2	114.3	16.6	14.98	22.31	E,X,G,S	0.337	8.56	EU IEU
4 1/2	114.3	20	18.69	27.84	E,X,G,S	0.43	10.92	EU IEU
5	127	16.25	14.87	22.15	X,G,S	0.296	7.52	IU
5	127	19.5	17.93	26.71	E	0.362	9.19	IEU
5	127	19.5	17.93	26.71	X,G,S	0.362	9.19	EU IEU
5	127	25.6	24.03	35.79	E	0.5	12.7	IEU
5	127	25.6	24.03	35.79	X,G,S	0.5	12.7	EU IEU
5 1/2	139.7	21.9	19.81	29.51	E,X,G,S	0.361	9.17	IEU
5 1/2	139.7	24.7	22.54	33.57	E,X,G,S	0.415	10.54	IEU
