API Alien (double Horse Head) Beam Pumping Unit CYJS10-5-73HB Oilfield

API Alien (double Horse Head) Beam Pumping Unit CYJS10-5-73HB Oilfield thumbnail-1
API Alien (double Horse Head) Beam Pumping Unit CYJS10-5-73HB Oilfield photo-1
US$ 10,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Hongsheng Oil
Contact Supplier Request Quote Chat Now
Lijin Hongsheng Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name Hongsheng Oil
Model Number CYJS10-5-73HB
Certification ISO API
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Meets API Spec 11E or Q / SL 1361 - 2002 standards, with the characteristic of a stroke length, small dynamic load,etc.



Product Features
Alien (double horse head) beam pumping unit using adjustable arc-shaped beam rear arm, between the beam and the beam connecting the special structure of the flexible member, the production strictly according to API Spec 11E or Q / SL 1361 - 2002 standards, with a stroke length, dynamic load is small, small torque fluctuations, high efficiency, low energy consumption, smooth, easy to start and so on. The aircraft is equipped with multi-function electrical cabinets, with short circuit and overload voltage protection, reactive power compensation, restoration from the start, the motor speed and other functions, low-powered devices are equipped with investment, easy maintenance and management. Saving 20-60% than conventional machines, installed power reduced by about 50%, and can save power system investment.
Mainly used for mining low-viscosity crude oil and high water content can also be mined for viscous crude oil.

Technical Parameters






Model



Rated rod load



Reducer rated torque



Red times



Stroke



Motor Power



Total Weight

(kN)
(kN.m)
(min-1)
(m)
(kW)
(kg)
CYJS6-3-18HB
60
18
3,2.5,2
5,7,9
15
14000
CYJS6-3-26HB
60
26
3,2.5,2
5,7,9
18.5
18000
CYJS8-3-26HB
80
26
3,2.5,2
5,7,9
18.5
18000
CYJS8-3-37HB
80
37
3,2.5,2
4,6,8
18.5
19000
CYJS10-3-37HB
100
37
3,2.5,2
4,6,8
18.5
20000
CYJS10-4.2-37HB
100
37
4.2,3.6,3
4,5 ,6
18.5
21000
CYJS10-4.2-53HB
100
37
4.2,3.6,3
4,5 ,6
18.5
21500
CYJS10-5-37HB
100
37
5,4.2,3.6,3
4,5 ,6
18.5
22000
CYJS10-5-48HB
100
48
5,4.2,3.6,3
4,5 ,6
22
23000
CYJS10-5-73HB
100
48
5,4.2,3.6,3
4,5 ,6
22
24000
CYJS12-5-48HB
120
48
5,4.2,3.6,3
4,5 ,6
22
25000
CYJS12-5-53HB
120
53
5,4.2,3.6,3
4,5 ,6
30
27000
CYJS12-5-73HB
120
73
5,4.2,3.6,3
4,5 ,6
37
28000


API Alien (double horse head) Beam Pumping Unit CYJS10-5-73HB oilfield
