Durable Square Vacuum Dryer with GMP requirement
Main Usage
Suitable to the materials-drying for the lines of medicine , chemical , foodstuff, and electronics.
Specialty
1 Under constant temperature if the vacuity of drum is improved ,the drying speed can be shortened.
2 Under constant vacuity if the heating temperature is elevated ,it can accelerate the drying speed .
3 If both the vacuity and heating temperature is elevated ,the drying speed can be shortened greatly .
If a condenser is accepted , the vaporized agent in the target materials can be recollected by condenser , which is the normal drying facility ,If Model JZJS-70 liquid loop pump vacuum unit is Used , the condenser can be omitted to save energy and investment .
Technical Data
Model |
YZG-600 |
YZG-1000 |
YZG-1400 |
FZG-15 |
Inner size of drying box (mm |
Φ600×976 |
Φ1000×1527 |
Φ1400×2054 |
1500×1400×1220 |
Outer size of drying box (mm) |
1135×810×1020 |
1693×1190×1500 |
2386×1675×1920 |
1513×1924×2060 |
layer of dry rack |
4 |
6 |
8 |
8 |
Distance between layers (mm) |
81 |
102 |
102 |
122 |
Size of dry tray (mm) |
310×600×45 |
250×410×45 |
400×600×45 |
480×630×45 |
Number of dry tray |
4 |
24 |
32 |
32 |
Use press.inside of pipe (Mpa) |
≤0.784 |
|||
Use temperature of rack () |
-35150 |
|||
No load vacuum inside box (Pa) |
1330(10mmHg) |
|||
Packing
If you want to send inquriy to me about our machine, could you please tell me?
1) What material you want to mix?
2) What capacity you expect ? (kg/batch or litre/batch )
3) What voltage you want? For example, 380V 50hz 3p; 440V 60Hz,3p; 220V...
(We only provide 3P, because our machines are all for industrial use,not for family.)
4) What material of the equipment you want? usually we adopt all stainless steel 304.
Then our communication will be more efficient.
