Specifications
1,Vertical slide switch&horizontal slide switch ROHS2,Long life span,high raliability.
3,THE BEST SERVICE !
Vertical slide switch&horizontal slide switch ROHS
Specification:
| Travell: | G:3.5mm |
| Rating: | 0.5A 50V |
| Timing(Optional): | 0.1m |
| Contact resistance: | 70mΩ |
| Insulation Resistance: | 100MΩ |
| Withstand voltage: | AC 500V for 1 minute |
| Oprating force: | 160-250G |
| Switching life: | 10000 cycs |
Shenzhen Ganhad Plastic Electronics Co.,Ltd: Established in 2001, our factory has
been focusing on switch over a decade, our products are mainly to America, Europe, Asia and Middle East.
Application: Our switches are widely used in the fields of small household products, communication
equipment, energy generator, electric tools, table lamp, electric motor, electric motor car, electric toy, UPS, medical facilities, socket, etc
Engineering: We serve product design, mould development, plastic part injection, hardware part pressing and product automatic assembly
Quality: We will inspect supplied material, production process and final product, we completely make quality
control for every pass with inspections including withstand voltage, insulating resistance, conductor, dimension,
external appearance, etc. Meanwhile random sampling is taken for inspections such as products' exotherm,
environmental protection and electrical life. All related raw materials are inspected according to ROHS detective.
Brand: We strive to maintain PRO-SW as our brand and to make professional switch.
The factory detail:
