ASCE 75 Steel Rail/ASCE 85 Steel Rail/ASCE 90 Steel Rail/ASCE 115 Steel Rail/

Negotiable MOQ: 50 Tons (Price negotiable depending on order volume and customization)

Key Specifications

Standard:

AISI

Grade:

55Q or U71MN or U75VM

Rail Heigth:

ASCE

Shanghai Gms Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Standard AISI

Grade 55Q or U71MN or U75VM

Rail Heigth ASCE

Bottom Width ASCE

Web Thickness ASCE

Head Width ASCE

Length ASCE

Place of Origin China

Model Number ASCE

Type Light Rail

Application Railway Rail

Weight ASCE

Secondary Or Not Non-secondary

Bolt Hole Diameter ASCE

Specifications

ASCE 75 Steel Rail/ASCE 85 Steel Rail/ASCE 90 Steel Rail/ASCE 115 Steel Rail/

1. Material :

Prime Newly produced Carbon Light Rail Products, mainly designed for

Guide Track for Mine, Construction and Crane & Hoist Track

2. Grades & Specification : ASCE Standard

3. Annual Production Capacity : 600,000mt

4. Table of Rail Section

Size (Nom WT)		Standard Sectional Dimension								Length
Per Yard	Per Meter	A	B	C	D	E	F	G	T	Length
ASCE25	(12.2kg)	2 3/4"	2 3/4"	1 1/2"	25/32"	31/64"	1 31/64"	1 29/128"	19/64"	up to 30ft
ASCE30	(15.2kg)	3 1/8"	3 1/8"	1 11/16"	7/8"	17/32"	1 23/32"	1 25/64"	21/64"	up to 40ft
ASCE40	(19.84kg)	3 1/2"	3 1/2"	1 7/8"	1 1/64"	5/8"	1 55/64"	1 71/128"	25/64"
ASCE45	(22.3kg)	93.66mm	93.66mm	50.8mm	26.99mm	16.67mm	50mm	41.67mm	10.72mm
ASCE60	(30.1kg)	4 1/4"	4 1/4"	2 3/8 "	1 7/32"	49/64"	2 17/64"	2.05"	31/64"
ASCE75	(37.2kg)	122.24mm	122.24mm	62.71mm	36.12mm	21.43mm	64.69mm	53.78mm	13.49mm
ASCE85	(42.3kg)	5 3/16"	5 3/16"	2 9/16"	1 35/64"	57/64"	2 3/4"	2 17/64"	9/16"
90ARA-A	(44.64kg)	142.9mm	130.2mm	65.1mm	37.3mm	25.4mm	80.2mm	73.8mm	14.3mm
115AREA	(56.9kg)	6 5/8"	5 1/2"	2 23/32"	1 11/16"	1 1/8"	3 13/16"	2 7/8"	5/8"

5. Chemical Composition & Mechanical Property
