27dBm indoor dual wide band repeater for GSM+DCS, CDMA+PCS, GSM+WCDMA, CDMA+WCDMA mobile communication network
Product Feature
* Provide quick coverage solution for small signal weak & block zones, reduce drop/off calls.
* Compact size, low consumption, easy installation, great coverage.
* Covering about 5500-13000m² without block or obstruct.
* Reduce cellphone transmit power and radiation, extend cellphone battery life.
* High linear design, low interference to BTS.
* Manual gain control function.
Available repeater model:
C27C-GD, C27C-CP, C27C-GW, C27C-CW
Standard Package
1) AC90-264V,DC12V/10A power supply adapter 1PCS
2) AC power cord(EU standard/ US standard/UK standard/ SA standard/China standard, etc) 1PCS
3) Installation kit 1PCS
4) User manual 1PCS
Recommended Accessories
1) Donor antenna: Log Periodic Dipole Aantenna (8.2dBi@806-960MHz, 9.5dBi@1710-2500MHz)
2) Service antenna: Omni Ceiling Antenna (2dBi@824-960MHz, 4.7dBi@1710-2500MHz)
3) 1/2" RF cable with connecter(Cable length customizable);
4) Splitter, coupler
Application
Electrical Specification
| Items | Uplink | Downlink | |||||
| Frequency Range | GSM900+DCS | 890 ~ 915 MHz/1710 ~ 1785 MHz | 935 ~ 960 MHz/1805 ~ 1880 MHz | ||||
| CDMA+PCS | 824 ~ 849 MHz/1850 ~ 1910 MHz | 869 ~ 894 MHz/1930 ~ 1990 MHz | |||||
| GSM900+WCDMA | 890 ~ 915 MHz/1920 ~ 1980 MHz | 935 ~ 960 MHz/2110 ~ 2170 MHz | |||||
| CDMA+WCDMA | 824 ~ 849 MHz/1920 ~ 1980 MHz | 869 ~ 894 MHz/2110 ~ 2170 MHz | |||||
| Max.Gain | ≥ 70dB | ≥ 75 dB | |||||
| Manual Gain Control | 31dB in step of 1dB | ||||||
| Automatic Gain Control | >20dB | ||||||
| Bandwidth | Wide Band | ||||||
| Ripple in Band | CDMA,GSM ≤8dB ; DCS,PCS ≤10dB;WCDMA ≤6dB | ||||||
| Max. Input Power Without Damage | 0 dBm | ||||||
| Output Power | ≥ 20 dBm | ≥ 24 dBm | |||||
| Intermodulation Products | 9KHz~1GHz | ≤-36 dBm | ≤-36 dBm | ||||
| 1GHz~12.75GHz | ≤-30 dBm | ≤-30 dBm | |||||
| Spurious Emission | 9KHz~1GHz | ≤-36 dBm | ≤-36 dBm | ||||
| 1GHz~12.75GHz | ≤-30 dBm | ≤-30 dBm | |||||
| Spurious Emission Mask( WCDMA ) | Complies with 3GPP TS 25.106 | ||||||
| Modulation Accuracy( WCDMA ) | Complies with 3GPP TS 25.106 | ||||||
| Peak Code Domain Error( WCDMA ) | Complies with 3GPP TS 25.106 | ||||||
| ACRR( WCDMA ) | ≥ 30dB @±5MHz&±10MHz | ||||||
| Noise Figure @ max. gain | ≤ 8 dB(Typical) | ||||||
| Return loss | ≤-10 dB | ||||||
| Time Delay | ≤0.5 μs | ||||||
| MTBF | >50000 hours | ||||||
| Power Supply | AC:90~265V,50/ 60Hz;DC:12V 10A | ||||||
| Power Consumption | < 60W | ||||||
| Impedance | 50 ohm | ||||||
| Input Signal Level | Normal | At the edge of green and orange( -50dBm or more) | |||||
| Low | Green | ||||||
| High | 1-5dB range:Orange; >20dB:Red | ||||||
Mechanical Specification
| RF Connector | N-Female | ||||||
| Switch | Power Switch,Manual Gain Control Switch | ||||||
| Cooling | Heatsink Convection cooling | ||||||
| Dimensions (D x W xH ) | 300*268*58(mm) | ||||||
| Weight | < 4.5 Kg | ||||||
| Installation Type | Wall Installation | ||||||
| Environment Conditions | IP40 | ||||||
| Humidity | < 90% | ||||||
| Operating Temperature | -10℃ ~ 55℃ | ||||||
Packaging: standard exportation carton (paperboard box with protective polyfoam)
Shipping: by express, airplane or sea
Warranty:
one year warranty for the repeater, misoperation and man-made damage is not within the scope of free warranty.
