Home > Electrical & Electronics > Telecommunication & Broadcasting > Repeater > 1000-4000 Sq.m GSM Cell Phone Repeater/ 900MHz RF GSM Relay Booster

1000-4000 Sq.m GSM Cell Phone Repeater/ 900MHz RF GSM Relay Booster

Name: 1000-4000 Sq.m GSM Cell Phone Repeater/ 900MHz RF GSM Relay Booster
Brand: Amplitec
SKU: 112881159
Availability: InStock

1000-4000 Sq.m GSM Cell Phone Repeater/ 900MHz RF GSM Relay Booster thumbnail-1

1000-4000 Sq.m GSM Cell Phone Repeater/ 900MHz RF GSM Relay Booster photo-1

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Amplitec

Model Number:

W20B-GSM(01)

Contact Supplier Request Quote Chat Now

Foshan Amplitec Tech Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangdong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Amplitec

Model Number W20B-GSM(01)

• Product Details

• Product Feature

Product Name: GSM Cell Phone repeater/ 900MHz RF GSM Relay Booster

Product Model: W20B-GSM(01)
Product Code: CXT1011-004

Provide quick coverage solution for weak & blind GSM 900 MHz mobile signal zones, reduce drop/off calls.
Compact size, micro, elegant design, easy installation and operation.
Low consumption, low interference to BTS, high linear design.
Lowers cell phone power emissions and extends phone battery life.
Use advanced high linear IF saw filter technology.
MCG(Manual Gain Control) function to ensure flexible GSM network coverage.
ALC can limit output power to ensure stable GSM cell phone signal coverage.
Apply to approximate 1500-4000 square meters coverage..
Perfect Indoor Repeater solution of GSM 900MHz mobile signal extender.

• Standard Package

1) DC:12V/3A power supply 1PCS
2) AC power cord (EU standard / US standard/UK standard/SA standard/China standard, etc) 1PCS

• Recommended Accessories

1) Donor antenna: Log Periodic Dipole Aantenna (8.2dBi@806-960MHz)
2) Service antenna: Omni Ceiling Antenna (2dBi@824-960MHz)
3) 1/2"RF cable with connector (cable length optional)
4) Splitter, Coupler

• Available Items:

1) Output power for 20dBm,1-sub band in any one of GSM, DCS system .
2) Repeater models:W20B-GSM(01), W20B-DCS(01).

• Picture Detail

• Specification

• Electrical & Mechanical Specification

Items		Uplink	Downlink
Frequncy Rage	GSM	890-915 MHz	935-960 MHz
Bandwidth		Availale upon request
Gain		65 ± 2dB	70 ± 2dB
Output Power		15 ± 2dBm	20 ± 2dBm
AlC not Active		-	• Green
ALC Acive 5-10dB		-	• Orage
ALC Active 15-20dB		-	• Red
Power Consumption		< 20W
Power Supply		DC:12V/3A
RF Connector		N-Female
Weight		≤ 2.5kg
Size		250 × 145 × 53 mm
Environment condition		IP40

• About Amplitec

Amplitec Corporation, a manufacturer was established in 2005 year, is in the forefront of Wireless revolution. With solid track record of successful development and deployment of advanced radio communication technologies, Amplitec is enabling operators worldwide for transition to a phenomenon of "seamless coverage".

Amplitec develops reliable indoor and outdoor coverage and optimization mobile signal repeater and booster's solutions for offices, restaurants, hotels, commercial centers, countryside, residential areas,tourist resorts, and stadiums on various GSM850, GSM900, GSM1800, GSM1900, CDMA800 PCS1900, IDEN, EGSM networks as well as WCDMA, 3G and TD-SCDMA systems.

• Our Office and Production Workshop

• Manufacturing Facilities

• Certificates of ISO, CE, Patent

• Exhibitions

If this GSM Cell Phone repeater/ 900MHz RF GSM Relay Booster or any other cell repeater meet your requried, please feel free to contract with us .

More detail please visit our official website:

Contact: Jason
Skype ID: LJC_Amplitec
