Refrigerator Compressor Capacitor CBB65 Series

Refrigerator Compressor Capacitor CBB65 Series thumbnail-1
Refrigerator Compressor Capacitor CBB65 Series photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
JKCN
Model Number:
CBB65
Contact Supplier Request Quote Chat Now
Zhejiang Jiukang Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO OR SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name JKCN
Model Number CBB65
Type Other, Polypropylene Film Capacitor, Round /Oval
Application AC / Motor
Package Type Surface Mount
Capacitance 1-100uf
Rated Voltage 220-450V
Operating Temperature -40-+70

Specifications

1.Explode-proof structure
2.Applicable in air conditioner,refrigerator etc.
3.High performance
4.Long life
5.CE approval







Product Character:



This product uses thickened metalized polypropylene film as a dielectric,

coiled by high speed winding machine, encapsulated with Aluminum body.

It is treated by using refined castor oil as impregnant in the high temperature

and vacuum environment to make the capacitor more stable with long working life.

Mean while based on the principle of safety and proof-explosion,this kind of capacitor has been used the second generation mechanical

 explosion proof design to strengthen the reliability.





Features of CBB65 capacitor
1. The product is soaked by special oil, thus it possesses stable electric performance and explosion preventing function.
2. The radiating performance is good, the temperature rise is low and the life is long.
3. Single product could be made into quite high voltage and capacity.





Service Condition



1.Altitude:Applied in the area under 2000 meters.

2.Service temperature:The environment temperature is -25~+70 degree centigrade

3.Relative humidity:Below95%

4.Dirtiness:There's no conducting dust and corrosive gas in the service area.

5.Residual voltage in service:Under10% of rated voltage.







Technical indicators



1.Rated voltage: 200V,250V,400V,450V,500V

2.Rated frequency:50/60Hz

3.Operation mode:Continuous
4.Tangent of loss angle: ≤ 0.2%

5.Capacitor deviation:±5%,±10%

6.Top allowable overvoltage:1.1Un

7.Top allowable overcurrent:1.3In

8.Insulation:Between terminal:2Un.2seconds;None permanent arcover.Between pole and shell:3KV.2seconds;None arc over







Technical Data



Climate type

40/70/21

Capacitance tolerance

+/-5%

Test voltage

T-T: 2Un     T: 2s

T-C: 2Un+1000V≥2000V     T: 10s

Insulation resistance

≥3000MΩ

Loss tangent

tgδ ≤0.002(50/100Hz )







Dimensions(mm)



Capacitance

(µF)

250V- 450V

D×H(mm)

2









40×70

3

4

5

6

7

8

10

12

15

45*90

20

45*90

25



45*90

30

45×90

35

50×110

40

50×110

45

50×110

50

50×110

55

60×110

60

60*110

70

60*110

80

60×150

100





We could design and manufacture as customer's specified specs and dimensions. We can products with any

voltage,capacity,outlet line structure and installing requirements.



Application:

This capacitor widely used for air-conditioners ,refrigerators,generators,illuminating lamps etc.

We accept OEM.







Refrigerator compressor capacitor CBB65 seriesRefrigerator compressor capacitor CBB65 series

Refrigerator compressor capacitor CBB65 seriesRefrigerator compressor capacitor CBB65 seriesRefrigerator compressor capacitor CBB65 series
