Air Conditioner Part Motor Run Capacitor CBB65

Name: Air Conditioner Part Motor Run Capacitor CBB65
Brand: JKCN
SKU: 112871393
Availability: InStock

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

JKCN

Model Number:

CBB65

Zhejiang Jiukang Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO OR SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name JKCN

Model Number CBB65

Type Polypropylene Film Capacitor

Application AC / Motor

Package Type Surface Mount

Capacitance 1-100uf

Rated Voltage 220-450V

Operating Temperature -40-+70

Specifications

AC Motor Capacitors have CE,UL & ROSH certificates . Used for 50/82hz A.C single phase motor, like pumps, micro motor and so on.

air cooler motors capacitor strength:
1.ac compressor capacitor
2. aluminum shell capacitor

air cooler motors capacitor details:

CBB65 features:

1.The capacitor is low loss,and the anticipated operating life is long.

2.Explosion-proof capacitors,so the capacitor is highly safe

3.The CBB65 capacitor is widely used for air conditioner, refrigerators,compressor,etc.

Technical Data for CBB65:
Product type	polypropylene Film Capacitor
Capacitance range	3uF~100uF
CapacitanceTolerance	±5% or according to customers’ requests.
Rated Voltage	200VAC, 250VAC, 370VAC, 400VAC, 440VAC ,450VAC, 500VAC,550VAC,600VAC ,630VAC ,660VAC
Rated frequency	50Hz/60Hz
Operating Temperature	-40° C~+70° C-40° C~+85° C
Class of safety protection	P2
Testing voltage	T-T: 2.0Un/60S
Insulation resistance	> =3000s
Tangent of loss angle of a capacitor	tanσ ≤ 0.0020 (100Hz)
Life expectancy	classC
