Help CenterBROACHING MACHINE
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Maharashtra, India
Brand Name:
GAMUT, GAMUT
Model Number:
GAMUT-VB1, GAMUT-VB2, GAMUT-VB3 AND GAMUT-VB4, GAMUT-VB1, GAMUT-VB2, GAMUT-VB3 AND GAMUT-VB4
Payment & Shipping
Payment Methods:
Port of Shipment:
MUMBAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
VERTICAL BROACHING MACHINENegotiableMOQ: 1 Set -
HYDRAULIC VERTICAL BROACHING MACHINENegotiableMOQ: 1 Set
-
HYDRAULIC PULL DOWN VERTICAL AUTOMATIC BROACHING MACHINENegotiableMOQ: 1 Set
-
Keyway Vertical Hydraulic Broaching MachineNegotiableMOQ: 1 Set
-
HYDRAULIC VERTICAL PULL DOWN BROACHING MACHINEUS$ 12,940 - 12,940MOQ: 1 Set
Place of Origin
Maharashtra, India
Brand Name
GAMUT, GAMUT
Model Number
GAMUT-VB1, GAMUT-VB2, GAMUT-VB3 AND GAMUT-VB4, GAMUT-VB1, GAMUT-VB2, GAMUT-VB3 AND GAMUT-VB4
Type
Other, BROACHING MACHINE
Specifications
HYDRAULIC VERTICAL BROACHING MACHINE ARE AVAILABLE IN 750, 1000, 1200MM STROKE WITH 3TON TO 15TON CAPACITY. WITH FOUR GUIDE BARGAMUT Vertical Broaching Machines are Pull Down type and Hydraulically operated. These Machines are precisely made with Hardened, Ground and Chrome plated 4 guide bar with suitable linear bushes fitted on Broach Puller holding guide plate which are bored on highly precise Jig boring machine to maintained accuracy with allied parts. The main parts are suitably heat treated to give maximum accuracy continuously. These machines are heavy and robustly constructed to minimized vibration during broaching operation.
FEATURES:
- Built in coolant Equipment.
- Built in Hydraulic Power Pack.
- Splash Guard.
- Broach Puller to suit broach shank and guide plate.
- Broach holding guide plate move up and down on 4 Hardened and Ground guide bar.
- Hydraulic Broach Retriever system optional item at extra cost.
TECHNICAL SPECIFICATION
| MODEL | GAMUT-VB1 | GAMUT-VB2 | GAMUT-VB3 | GAMUT-VB4 |
| STROKE OF BROACHING MM | 750/1000/1200 | 750/1000/1200 | 750/1000/1200 | 1200 |
| BROACH PULLING FORCE KG | 3.500 | 6,000 | 10,000 | 15,000 |
| BROACH FEEDING SPEED M/M | 0-5 | 0-5 | 0-3 | 0-3 |
| BROACH RETURN SPEED M/M | 5 | 5 | 3 | 3 |
| MAX BORE ON WORKING TABLE | Φ90 | Φ90 | Φ110 | Φ110 |
| WORKING TABLE IN MM | 400 X 600 | 500 X 700 | 650 X 750 | 750 X 850 |
| HYDRAULIC TANK CAPACITY LTR | 125 | 150 | 250 | 250 |
| MAX HYDRAULIC PRESSURE σ | 100 | 100 | 100 | 100 |
| HYDRAULIC MOTOR HP | 5 | 7.5 | 15 | 20 |
| HYDRAULIC PUPM LPM | 23 | 28 | 54 | 54 |
| COOLANT MOTOR HP | 0.15/0.25 | 0.15/0.25 | 0.50 | 0.50 |
| COOLANT TANK CAPACITY LTR | 100 | 150 | 150 | 150 |
| WEIGHT KG | 1250 | 1650 | 2300 | 3500 |
