CE approved Reach Truck Full Electric Pallet Stacker (CQD16)
Negotiable
/ Unit
1 Unit(Min.Order)
- 500 Unit / Units per Month
- shanghai
- T/T
You May Like
-
Capacity 1000kg-2000kg Half-Electric Power Stacker (CDSD10)
-
2 Ton Electric Forklift New Lifter for Sale (CPD20E)
-
3.0 Ton New Battery Electric Forklift Type (CPD30)
-
Price Competitive Forklift 1 - 3 Ton Electric Forklift (CPD30)
-
3.0 Ton 4-Wheel Battery Electric Forklift (CPD30)
-
High Quality 2.0 Ton Electric Forklift with Forklift Battery (CPD20E)
Product Details
| Condition | New | Place of Origin | Shanghai, China | |
| Brand Name | Marshell | Model Number | CQD16 | |
| Type | Manual Pallet Truck | Power Souce | AC Motor | |
| Rated Loading Capacity | 1600KG | Max. Lifting Height | 3000mm | |
| Min. Lifting Height | 80mm | Fork Length | 2320MM | |
| Fork Width | 1035MM | Overall Dimensions | 100/40/1070MM | |
| Certification | CE | After-sales Service Provided | Overseas third-party support available |
Product Description
CE approved Reach Truck Full Electric Pallet Stacker (CQD16)
Main configuration
1, maintenance-free ac drive system
2, electronic steering system
3, 24 v / 270 ah high-capacity lead-acid batteries
4, Curtis communication controller
5, import a two-speed hydraulic power unit
6, the side with quick replacement battery structure
7, a variety of specifications door frame to meet different customer needs
suitable mode
1. Vertical driving wheel, driving efficiency, easy installation & maintenance.
2. Compact struture and low gravity.
3. Tilting system forks easy for loading and stacking.
TIPS
Does not apply to contain flammable and explosive gas or dust
CE approved Reach Truck Full Electric Pallet Stacker (CQD16)
| Model | CQD10 | CQD16 | CQD20 |
| Loading capacity | 1000KG | 1600KG | 2000KG |
| Loading center distance | 500MM | 500MM | 500MM |
| Wheelbase | 1100MM | 1400MM | 1500MM |
| Servise weight (with battery) | 1500KG | 1600KG | 2500KG |
| Tyre size, drving wheel | 230/75MM | 230/75MM | 230/75MM |
| Tyre size, loading wheel | 180/55MM | 210/85MM | 210/85MM |
| Tyre size, balance wheel | 130/55MM | 130/55MM | 130/55MM |
| Driving wheel+Loading wheel/Balance wheel | 1+2/2 | 1+2/2 | 1+2/2 |
| Front overhang | 100mm | 130mm | 130mm |
| Lift height | 2500/3000mm | 3500/4000mm | 4500/5000mm |
| Height of triller in drive position min./max. | 1100/1400mm | 1100/1400mm | 1100/1400mm |
| Height, mast lowered | 1725/1925mm | 2225/2475mm | 2015/2240mm |
| Overall lengh | 2250MM | 2320MM | 2420MM |
| Overall width | 1000MM | 1035MM | 1035MM |
| Turn radius | 1350MM | 1640MM | 1760MM |
| Fork dimensions | 100/35/1070MM | 100/40/1070MM | 100/40/1070MM |
| Fork carriage width | 200-725mm | 200-725mm | 200-725mm |
| Aisle width for pallets 1000*1200 crossways | 2500mm | 2800mm | 2900m |
| Aisle width for pallet 800*1200 crossways | 2650MM | 2950MM | 3050MM |
| Reach distance | 350mm | 470mm | 470mm |
| Travel speed(laden/unladen) | 4/5KM/H | 4/5KM/H | 4/5KM/H |
| Lift speed(laden/unladen) | 30/50MM/S | 25/45MM/S | 18/40MM/S |
| Max. gradeability(laden/unladen) | 5/8% | 5/8% | 5/8% |
| Driving motor | 1.5KW | 1.5KW | 1.5KW |
| Lift Motor | 2.2KW | 3KW | 3KW |
| Battery volts./Cap. | 24V 240AH | 24V 240AH | 24V 240AH |
| Container qty (20FT/40FT/40HQ) | 4/8/8PCS | 4/8/8PCS | 4/8/8PCS |
CE approved Reach Truck Full Electric Pallet Stacker (CQD16)
