Specifications
Alloy A1060/A1050/A1350 Temper:OThickness: 0.2-3.0mm
Tolerance:0.01
Width:20-1300mm
Tolerance:0.1/0.2
Alu-strip with Round Edge for Power Transformer Winding
Henan Huto Aluminium Industry Co.,Ltd
Your faithful Angel
Skype:angle19880929
Tel: 0086-371-86616817
Fax:0086-371-86616819
Mobile:0086+15803826462
Alu-Alloy A1060/A1050/A1350 Temper:O
Thickness 0.2mm-0.3mm 0.4-0.8mm 1.0-2.0mm 2.0-3.0mm
Tolerance +/-0.015mm +/-0.02mm +/-0.01mm +/-0.06mm
Width 20-100mm 100-200mm 201-500mm 501-1300mm
Tolerance +/-0.1mm +/-0.2mm +/-0.2mm +/-1.0mm
Alloy Si Fe Cu Mn Mg Cr Ni Zn Ca V Ti Other Min.Al
1050 0.25 0.40 0.05 0.05 0.05 - - 0.05 - 0.05 0.03 0.03 99.50
Alloy Si Fe Cu Mn Mg Cr Ni Zn Ca V Ti Other Min.Al
1060 0.25 0.35 0.05 0.03 0.03 - - 0.05 - 0.05 0.03 0.03 99.60
Alloy Si Fe Cu Mn Mg Cr Ni Zn Ca V Ti Other Min.Al
1070 0.20 0.25 0.04 0.03 0.03 - - 0.04 - 0.05 0.03 0.03 99.70
Alloy Si Fe Cu Mn Mg Cr Ni Zn Ca V Ti Other Min.Al
1350 0.10 0.40 0.05 0.01 - 0.01 - 0.05 0.03 - - 0.03 99.70
Mechanical Property:
Enlongation: >25%
Density in 20°C: 2.703kg/cm
Our products: Aluminium strip
We are suppling our customer a wide range of aluminium strip.aluminium coil.aluminum strip.aluminum coil.which are manufactured from high grade quality raw materials.These aluminium slitted coils are widely know for durability and quality.These aluminim slitted coils are available at industrial leading price.They are widly used in cable wrapping.Aluminium plastic composite pipe,electrical transformer.radiator etc.
Any futher assistance from me,please feel free to contact me!
Or should you be interested in any item ,don't hesitate to contact me!
