Specifications
1060 Aluminium coil for transformer winding1.alloy:1xxx,3xxx,5xxx2.Thickness:0.2-4.0mm
3.width:25-1500mm
4.Free sample
Packaging & Delivery
| Packaging Detail: | export packing : anti-water paper ,steel strips ,wood pallect etc. |
| Delivery Detail: | 15-20 DAYS |
Advantage:
we are professional manufacturer can arrange production in advance and provide fatory price!
Specifications
1060 alloy aluminum coil for transformer
1)temper :HO
2)0.2mm-4mm thick
3)22mm-1890mm width
4)SGS cerificate
Aluminum coil & strips for transformer -alloy 1060 O temper
1. aluminum alloy :1060
2. temper : O temper
3. tensile strengh : 55-90MPA ,elongation : >20%
4. specification tolearance
thickness : <1.6mm +/-0.03;
>or=1.6mm +/-0.04mm;
<0.9mm +/-0.02mm
width :+/-1mm
length : transformer dosage/machine * time feet
5. flatness : very flat and straight
6. surface quality :
1) rolling the surface to be processed sound, texture uniform, does not allow any cracks, corrosion, perforation, etc. absolute waste.
2) Band (Volume) Face material should be neat, does not allow crack, Alice edge, burr height is not greater than the thickness of the positive tolerance. Allow end-string layer of not more than 2MM, tower not more than 5MM, end to end except for 5 laps)
3) Band (Volume) timber volume should be tight, does not allow a loose layer of joints are not allowed. The two laps to allow a little head and tail roll flaw.
7. Coil ID :weight according to clients demand
8. Packing : stardard export packing .
Cutting machine :can cut into strips on your option ,mininium 22mm .
