High Quality Tungsten Carbide,Carbide Rod,Tungsten Carbide Rod

High Quality Tungsten Carbide,Carbide Rod,Tungsten Carbide Rod thumbnail-1
High Quality Tungsten Carbide,Carbide Rod,Tungsten Carbide Rod thumbnail-2
High Quality Tungsten Carbide,Carbide Rod,Tungsten Carbide Rod thumbnail-3
High Quality Tungsten Carbide,Carbide Rod,Tungsten Carbide Rod photo-1
High Quality Tungsten Carbide,Carbide Rod,Tungsten Carbide Rod photo-2
High Quality Tungsten Carbide,Carbide Rod,Tungsten Carbide Rod photo-3
US$ 50 - 80 MOQ: 10 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
HengHui
Alloy Specification:
TK101-TK108,TC10-TC80,TP01G-TP05G,KG,YX,DK,JC and etc.
Contact Supplier Request Quote Chat Now
Chongqing Henghui Precision Mold Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing Shanghai or as to buyer's requirements
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Chongqing, China
Brand Name HengHui
Alloy Specification TK101-TK108,TC10-TC80,TP01G-TP05G,KG,YX,DK,JC and etc.
Particle 0.6-9μm

High Quality Tungsten Carbide,Carbide Rod,Tungsten Carbide Rod







Features:



Made from 100% raw virgin material
High hardness &density
Good corrosion resistance
Good abrasive resistance



Product Overviews

 High Quality Tungsten Carbide,Carbide Rod,Tungsten Carbide RodHigh Quality Tungsten Carbide,Carbide Rod,Tungsten Carbide Rod

Related Products

 High Quality Tungsten Carbide,Carbide Rod,Tungsten Carbide Rod

Product Description



High Quality Tungsten Carbide,Carbide Rod,Tungsten Carbide Rod



PARAMETERS OF MATERIAL
Application Material WC±0.5% Co±0.5% Fineness
μm		 Proportion
g/cm³		 Hardness
HRA		 Breaking-resistant
kg·f/mm²

Impact

strength
kg·f-m/mm²

 Remarks
Anti-abrasion
tools		 TK101 96 4 0.8-2 15.05 92.5 280 0.2

drawing thread/
drawing tube/
nozzle/powder

metallurgy die
TK102 96 5 1-2 15 92 310 0.26
TK103 94 6 2-3 14.9 90.5 320 0.28
TK104 91 9 2-3 14.61 89.3 340 0.52
TK105 88 12 1-2 14.3 89.3 360 0.55 shearing die/
punch head/
extrusion die
TK106 88 12 2-3 14.31 88.9 340 0.58
TK107 86 14 2-3 14.12 87.9 320 0.65
TK108 85 15 1 13.95 89.5 360 0.7
Anti-resistan
 tools		 TC10 85 15 3-6 13.8 86 270 0.78

special for

Galvanized

iron screw

die using
TC20 80 20 2-6 13.41 85.3 270 0.8
TC30 82 18 2-6 13.75 85 300 0.8 below 20φ
screw die
TC40 76 24 2-6 13.22 82.8 270 0.9

Forging die with

well impact

resistance
TC50 85 15 3-6 14.02 85 270 0.78
TC60 80 20 3-6 13.58 84 280 0.85

Screw die above

20φ
TC70 78 22 6-9 13.39 82.5 240 0.9 nut forming die
TC80 75 25 6-9 13.12 81.5 220 0.95

Forging die with
 well impact

resistance
Non magnetic TP01G 91 9%Ni 0.8 14.36 91.3 280 0.2

magnetic

materials/
forming die
TP02G 88 12%Ni 0.8 14.05 90 280 0.3
TP03G 85 14%Ni 1-2 14.15 86.5 260 0.39
TP04G 80 20%Ni 2-3 13.6 82 240 0.55
K Grade KG05 94 6 1 14.8 92.2 300 0.3

drill/cast iron/

cutter
KG08 93 7 1-2 14.75 91.8 300 0.33
KG11 93 7 1-2 14.75 91.2 300 0.35
KG546 93 7 1-3 14.75 90.2 320 0.45
Ultramicron YX10u 95 5 ≥0.6 14.8 94 360 0.2

PCB drill/

Non-metallic

cutter
YX11u 94 6 ≥0.6 14.65 94.5 360 0.2
YX12u 94 6 0.8-1 14.85 92.2 360 0.23

Machining tool

for steel cast

iron drill/milling

cutter
YX13u 93 7 ≥0.6 14.65 93.1 380 0.2
YX14u 90 10 0.6 14.35 92.3 380 0.25
YX15u 90 10 0.6-0.8 14.4 91.8 380 0.3
YX16u 90 10 0.6-0.8 14.4 91.3 400 0.3
YX17u 88 12 0.6-0.8 14.08 91.3 370 0.33
YX18u 88 12 0.6 14.15 92.4 400 0.35
YX19u 88 12 0.6 14.1 92.5 350 0.34
YX20u 87 13 0.8 14.15 90 360 0.38

progressive

press tool/

cutter
YX21u 85 15 0.8 13.95 90 360 0.4
YX22u 82 18 0.6 13.5 90 400 0.85
Mining tools DK8C 92 8 3-6 14.73 88.5 250 0.6

construction

drill
DK9C 91 9 3-9 14.61 97.8 240 0.67
DK10C 90 10 3-6 14.5 87 250 0.65
DK11C 89 11 3-9 14.42 96.5 270 0.72
DK12C 88 12 3-9 14.31 87 260 0.75
DK13C 87 13 6-9 14.22 85.5 280 0.8
DK14C 82 18 6-9 13.75 83.5 270 0.85
Sawtooth JC06 97 3 0.6-0.8 15.05 94.5 270 0.3

Woodworking

saw
JC08 95 5 1-3 14.90  92 280 0.3
JC10 94 6 1-3 14.80  91 310 0.32











Company Information





Henghui Precision Mold Co., Ltd  are a professional manufactory for tungsten carbide blanks and all kinds of tools&dies,including carbide strobe blanks,STB blanks, carbide bar/rods, carbide slitting saws,coated inserts,endmills ,carbide dies and many

customized products.Also, we can provide custom service.





♦Strict quality control system:
1.Before production, we will test the material for density, hardness, HRA, TRS. Only the material pass the test, we will go to the next step for production.
2.We also have responsible QC person to follow the inspection for semi-product during production for every batches, every types.
3.After we finished production, we need to test it again before we send them to you, with all mechanical properties.






♦ Guarantee:

We will put the quality cerfiticates into each cartons with all necessary data, if anything different from our agreement or standard, we guarantee that we will send you the replacement or return the payment, your decision.







After-Sales Service



For more further information please  Click "Send" Now!!

It's our pleasure to provide you good quality products with good price and service always.
