High Frequency Welding Machine, Cinema Screen Welding Machine, Large Cover Welding Machine, Coating Fabric Welding Machine
US$ 36,800 - 38,600
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Hipower
Model Number:
HR-25KWA
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Semi Auto Cylinder Edge Curling Machine for Transparent PlasticUS$ 3,300 - 3,800MOQ: 1 Unit -
Automatic Rotary Cylinder Cover Welding MachineUS$ 1,000 - 30,000MOQ: 1 Set
-
Automatic Turntable High Frequency Plastic Welding Equipment for PVC,PET,APET,PETGUS$ 1 - 16,600MOQ: 1 Piece
-
High Frequency PVC Folding Box Welding MachineUS$ 1 - 19,800MOQ: 1 Piece
-
High Frequency Welding MachineUS$ 1 - 8,900MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Hipower
Model Number
HR-25KWA
Voltage
380V 50/60Hz
Power
25KW
Frequency
13.56MHz
Welding Area
50mm*50mm*1000mm
Dimensions
W1200*H1800 with customizedable length of working table
Weight
2800kg
Usage
cinema screen welding
After-sales Service Provided
Engineers available to service machinery overseas
High Frequency Welding Machine, Cinema screen welding machine, Large cover welding machine, Coating fabric welding machine
- Applications: For tarpaulin/canvas, tents, movie / cinema screen, large cover, coating fabric, impounding reservoir and advertisements board, ect. welding / sealing / making .
- Power: Customized(until now our biggest power machine is 35KW)
- Series: F, F1, F2, C, 2C, Auto-walking.
- Colors: Customized(now we have made green, blue and creamy white)
- Dies: Straight flat die, straight die with lines, curved die with lines, etc.
- Configurations: 5557 sparkle proof device, high frequency auto tuning system, servo motor, PLC control, etc. Standard configuration use international well known brand(Toshiba, OMRON, etc.) Itcan be customized as well.
- Technically: Our high frequency tarpaulin welding machines have CE certification. We have developed full automatic welding machines. Our auto walking high frequency tarpaulin welding machines have no limited length.
- Specifications of High Frequency Welding Machine, Cinema screen welding machine, Large cover welding machine, Coating fabric welding machine C Series
Model |
HR-8KWA |
HR-10KWA |
HR-12KWA |
HR-15KWA |
HR-25KWA |
||
Output Power of Generator |
8000W |
10000W |
12000W |
15000W |
25000W |
||
Voltage |
380V 3P 50/60Hz or customized |
||||||
Frequency |
27.12MHz |
13.56MHz |
|||||
Input power |
15KVA |
18KVA |
20KVA |
25KVA |
35KVA |
||
Rectifier |
Silicon Diode |
||||||
Oscillation tube |
7T69RB |
E3069 |
E3130 |
8T85RB |
8T25RA |
||
Max pressure |
500kg |
600kg |
800kg |
1000kg |
1500kg |
||
Max gap of electrodes |
100mm |
||||||
Size of active horn |
100mm |
||||||
Size of Upper Electrode (W*H*L) |
50*50*800mm |
50*50*800mm |
50*50*900mm |
60*60*900mm |
50*50*1000mm |
||
Size of Work Table (L*W) |
450*1050mm |
450*1050mm |
450*1150mm |
450*1150mm |
450*1250mm |
||
Welding time |
0~10S |
||||||
...
