Home > Industrial Equipment & Components > Bearing > Deep Groove Ball Bearing > Tractors Used Cheap Ball Bearing 6208

Tractors Used Cheap Ball Bearing 6208

Tractors Used Cheap Ball Bearing 6208 thumbnail-1
Tractors Used Cheap Ball Bearing 6208 photo-1
US$ 0.1 - 50 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
NACHI
Bore Size:
40,
Outside Diameter:
80,
Contact Supplier Request Quote Chat Now
Nantong Shuangfeng Hardware Mechanical Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or ningbo or qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name NACHI
Bore Size 40,
Outside Diameter 80,
Model Number 6208
Precision Rating p0 p6 p5 p4
Seals Type open
Number of Row Single Row
Place of Origin Shanghai, China

Specifications

NACHI Bearing 6208
1.certification:CE/IAF/SGS
2.GMC supplier
3.more quality high-speed lower prices
4.Offer free samples

 Deep Groove ball bearings are the most popular of all the ball bearing types because they are available in a wide variety of seal, shield and snap-ring arrangements.The bearing ring grooves are circular arcs made slightly larger than the radius of the ball.



tractors used cheap Ball Bearing 6208



Bearing
NO.		 I.D O.D W Load Rating
(KN)		 Steel Ball Parameter Max Speed
d D B Dynamic Static NO. Size Grease Oil
mm inch mm inch mm inch Cr Cor mm r/min r/min
6200 10 0.3937 30 1.1811 9 0.35433 5.1 2.39 11 2.381 22000 26000
6201 12 0.4724 32 1.25984 10 0.3937 6.1 2.75 12 2.381 24000 32000
6202 15 0.5906 35 1.37795 11 0.43307 7.75 3.6 14 2.381 19000 23000
6203 17 0.6693 40 1.5748 12 0.47244 9.6 4.6 16 2.381 18000 21000
6204 20 0.7874 47 1.85039 14 0.55118 12.8 6.65 14 3.175 16000 18000
6205 25 0.9843 52 2.04724 15 0.59055 14 7.85 15 3.500 13000 15000
6206 30 1.1811 62 2.44094 16 0.62992 19.5 11.3 18 3.500 11000 13000
6207 35 1.378 72 2.83464 17 0.66929 25.7 15.3 15.3 3.500 9800 11000
6208 40 1.5748 80 3.1496 18 0.70866 29.1 17.8 22 3.500 10000 13000
6209 45 1.7716 85 3.34645 19 0.74803 32.5 20.4 22 3.969 6200 /
6210 50 1.9685 90 3.5433 20 0.7874 35 23.2 24 3.969 7100 8300
6211 55 2.16535 100 3.937 21 0.82677 43.5 29.2 / / 6400 7600
6212 60 2.3622 110 4.3307 22 0.86614 52.5 36 / / 6000 7000
6213 65 2.55905 120 4.7244 23 0.90551 57.5 40 / / 5500 6500
6214 70 2.7559 125 4.92125 24 0.94488 62 44 / / 5100 6000
6215 75 2.95275 130 5.1181 25 0.98425 66 49.5 / / 4800 5600
6216 80 3.1496 140 5.5118 26 1.02362 72.5 53 / / 4500 5300
6217 85 3.34645 150 5.9055 28 1.10236 83.5 64 / / 4200 5000
6218 90 3.5433 160 6.2992 30 1.1811 96 71.5 / / 4000 4700
6219 95 3.74015 170 6.6929 32 1.25984 109 82 / / 3700 4400
6220 100 3.937 180 7.0866 34 1.33858 122 93 / / 3500 4200







 tractors used cheap Ball Bearing 6208tractors used cheap Ball Bearing 6208tractors used cheap Ball Bearing 6208tractors used cheap Ball Bearing 6208tractors used cheap Ball Bearing 6208tractors used cheap Ball Bearing 6208



Payment terms:



1. 30% T/T In Advance, 70% T/T Against The Copy Of B/L



2. 100% L/C At Sight



3.as requested



Related industries:

tractors used cheap Ball Bearing 6208





Main production







Ball bearing



Deep groove ball bearings

Angular contact ball bearings

Self-aligning ball bearings

Thrust Ball Bearings

Angular contact ball bearings





Roller bearing

Cylindrical Roller Bearings

Taper Roller Bearings

Spherical Roller Bearings

Needle roller bearings

Thrust roller bearings





Other bearing

Pillow block bearing

Insert bearings

Joint bearings

Linear bearings











tractors used cheap Ball Bearing 6208







tractors used cheap Ball Bearing 6208tractors used cheap Ball Bearing 6208tractors used cheap Ball Bearing 6208tractors used cheap Ball Bearing 6208tractors used cheap Ball Bearing 6208tractors used cheap Ball Bearing 6208



why us







1) Reply you inquiry in 24 working hours.















2) Experienced staffs answer all your questions in fluent English















3) Customized design is available. OEM&ODM are welcomed.















4) Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.















5) Special discount and protection of sales area provided to our distributor and big regular customers.
